GB-29
GB
GB-28
DIGITAL SATELLITE RECEIVER
4.4 Modem Settings (DSB-A200C)
This is only for supporting PPV service via a CONAX
programmes.
● Modem Type: Please choose your modem type :
External or Advanced External.
● Prefix: When you are using extension line,
if necessary, to call outside, please
enter prefix number. To enter prefix
number or configuration string,
press GREEN(TEXT) key.
● Dialing: Please choose between Tone and Pulse.
NNoottee :
External modem
is only distributed by service Providers
and special distributors, not by SAMSUNG.
4.5 Time & Timer Setting
1) Time
● Place the cursor on this sub menu and press OK.
● Press
/
keys to change local time in Time Zone.
The local time will be changed according to your location.
GMT is referred to the standard time of Greenwich by
broadcasting signal. This cannot be changed.
2) Timer
15 timers are supported including timer(s) from EPG.
● Select the timer number on ‘Timer’ using
/
keys from 1 to 15.
● Press the
/
keys to choose event repetition you want to
reserve : Daily, Every Sunday, Every Monday, Every Tuesday,
Every Wednesday, Every Thursday, Every Friday, Every Saturday, Once.
If the timer is set from EPG screen, EPG is displayed on ‘Event Repetition’.
● Press the Numerical (0~9) keys to set the time you want and press the
/
keys to choose a switch time you want to reserve. If set time on ‘Switch-on
Time’ is same as one on ‘Switch-off Time’, this timer works for 24 hours.
● Select TV program to set the event program by pressing
/
keys.
When you press the TV/RADIO key, TV program and Radio program are toggled.
● Even you can set timers on Daily and Every Monday or Every Sunday, etc.
The priority has the repetition event which is less. For example, when you set timers
on Once and daily, ‘Once’ will work in stead of ‘Daily’ at that day. If the timer is
running, ‘Running’ message with a timer number is displayed on ‘Timer’.
OPERATING THE RECEIVER
To set User defined mode or EPG color mode
● Press the GREEN(TEXT) key.
The item which you want to change will appear.
● Move the item which you want to change using the
/
keys.
● Set the color you want using the
/
keys.
● Press the OK key to set.
To see the help message, press the YELLOW(ALT) key.
OSD Position
● Place the cursor on the position you want, and press the
/
keys or
/
keys until the screen moves to the position you want.
The screen will move to the position you want.
4.3 Media Settings
You can set the various media settings you want.
Place the cursor on this sub menu and press OK.
● Press the
/
keys to move the sub items and press the
/
keys to select the option.
● Press the OK key to confirm.
● Press the MENU/EXIT keys to exit the menu.
● Select the TV system :
PAL, SECAM, NTSC, PAL ➔ (auto) NTSC, SECAM ➔
(auto) NTSC, NTSC ➔ (auto) PAL, NTSC ➔ (auto) SECAM
● Select the TV type according to your TV: STANDARD
4: 3 ratio or WIDE SCREEN 16 : 9 ratio type.
● Select the aspect ratio conversion :
Letter Box, Pan & Scan, Mixed or Full.
● Select the Video Signal Type :
Composite, Composite + RGB, Composite + YUV or S-Video
● Select the RF Channel : Ch 21~Ch 69
● Select Broadcasting System : B/G, I or D/K
OPERATING THE RECEIVER
MF68-00316B(REV1.1)_GB 2/16/05 10:55 AM Page 28
