CFX75DZW, CFX95DZW Operation

Connection sockets, Emergency switch (when fitted) and USB port

(fig. 4, page 3)

7Operation

7.1 Before initial use

Reversing the lid opening direction

The lid hinges can be moved to the opposite side if you want to open the lids from

the opposite direction. To do this, proceed as follows:

➤ Open the lids and remove them (fig. 5 A, page 3).

➤ Remove the three screws per side hinge (fig. 5 B, page 3) and take off the

hinges.

➤ Remove the plastic covers from the new side hinge positions with a small screw-

driver and re-fit to old hinge positions.

➤ Re-fit the side hinges in the new positions.

➤ Remove the two plastic covers from the centre hinge (fig. 6 A, page 4).

➤ Remove the four screws from the centre hinge (fig. 6 B, page 4) and take off the

hinge.

➤ Remove the plastic cover from the new centre hinge position with a small

screwdriver and re-fit to old hinge position (fig. 6 C, page 4).

Item Description

1 Connection socket AC voltage supply

2 Fuse holder

3 Emergency switch

4 USB port for power supply

5 Connection socket DC voltage supply

NOTE

Before starting your new cooler for the first time, you should clean it

inside and outside with a damp cloth for hygienic reasons (please also

refer to the chapter “Cleaning and maintenance” on page 24).
