CFX75DZW, CFX95DZW Operation

7.14 Replacing the AC fuse

➤ Disconnect the power supply to the device.

➤ Pull off the connection cable.

➤ Pry out the fuse insert (fig. 4 2, page 3) with a screwdriver.

➤ Replace the defective glass fuse with a new one that has the same type and rating

(4 A ,250 V).

➤ Press the fuse insert back into the housing.

➤ Reconnect the power supply to the device.

7.15 Replacing the DC plug fuse

➤ Unscrew the contact pin housing (fig. 7 3, page 4) from the plug (fig. 7 1,

page 4).

➤ Replace the defective fuse (fig. 7 2, page 4) with a new fuse of the same type

and rating (3AG, Fast Acting, 10 A).

➤ Re-assemble the plug in reverse order.

7.16 Replacing the light PCB

➤ Disconnect the power supply to the device.

➤ Pry out the transparent cover with a screwdriver (fig. 8 A, page 4).

➤ Unscrew the PCB mounting screws (fig. 8 B, page 4).

➤ Pull out the plug from the PCB (fig. 8 C, page 4).

➤ Replace the defective light PCB with a new one.

➤ Fit the new PCB using reverse of removal instructions.

➤ Press the transparent cover back into the housing.

➤ Reconnect the power supply to the device.

DANGER! Danger of electrocution!

Disconnect the power supply and the connection cable before you

replace the device fuse.
