24
576
Mode
To
activate the MAX mode, press
MODE until the MAX symbol
appears . The measured maximum
temperature is displayed as long
as the trigger is pulled or locked
on. The real time temperature is
shown in the lower part of the dis-
play (NORM).
To
show which specific material
has been choosen for the specific
location, press MODE until the
name appears in the bottom line.
If “Free” appears, you can change
the emissivity settings by using
the Emiss. button, when not in
LOG mode.
See chapter The
Emiss. button!
To
show the minimum and maxi-
m
um temperature values during a
measurement at the bottom of the
display, press MODE until the two
v
alues appear.
