Fluke 576 [28/33] Sometimes a long beep and the red led above the display shines to indicate a problem check your display to find out which problem has occured
![Fluke 576 [28/33] Sometimes a long beep and the red led above the display shines to indicate a problem check your display to find out which problem has occured](/views2/1005391/page28/bg1c.png)
28
576
Troubleshooting
Symptom
Display Code Problem Action
Camera cannot Driver installation Open
send photos failed Harware Manager on
to the PC the PC to fix it
-O- Target temperature is over Select target
-U- or under range within unit’s specs
EEPROM-Err EEPROM error Contact Factory
CalAreaErr calibration errors Contact Factory
ProbCalEr
Flash needs Battery is low Replace Batteries
too long to
charge or does not
charge at all
Blank display Battery is dead Replace Batteries
Laser won’t Low or dead battery Replace Batteries
work
Ambient above 45°C (113°F) Operate unit in
45°C (113°F)
ambient or below
Display “ON” Display locked “ON” Disconnect the unit
from the PC
Photos lost Batteries changed before Wait for shutdown
shutdown or too long to end. (blank screen)
after removing old ones Change batteries within
two minutes of
removing old ones
PC displays “logger The setup in the unit and Click “OK”. Either save
file does not match in the PC software do not the current data to a
device logger setup” match new file name or find
the correct *.lgg file,
open it in “Setup
Device Logger”, save,
and redownload the
data with the “Data
Logger/Load Device
Data Logger”
Sometimes a long beep and the red LED above
the display shines to indicate a problem, check
y
our display to find out which problem has
occured.
