![Fluke 576 Инструкция по эксплуатации онлайн [29/33] 4835](/views2/1005391/page29/bg1d.png)
29
576
Symptom
Display Code Problem Action
Photo quality Light is insufficient for photo Use Photoflash
diminished with without flash always on (Dip switch
available light. “Auto/All”set to “All”
(Abrupt transitions or provide more
between color shades) ambient light.
Connection of unit Wrong com port selected Select correct com
to PC software or correct com port in use. or disconnect other
does not happen device from correct
when software started com port
No picture in More than one video Right mouse click
“Live” mode source is installed on the “Live” mode
window window. Choose
correct “Video source”
in the menu.
Unit indicates The light is too bright for Go to next location
“Use flash!” in a photo or reduce brightness.
bright light
Unit leaves LOG The last position has been used If another recording
after a photo and to record photo and data. of the data and
data recorded. photo is required, then
push Enter button and
use arrow keys to
re-record a position.
Photo Mem! All memory for storing photos 1. Download existing
has been used. photos and data and
clear memory.
- or -
2. If you don’t mind
losing photos
in the unit, you can go
to Setup in the unit,
push the button until
“Clear photo” appears
in the display and
press Enter.
