Mode - Thermocouple Settings
Lock
C/
F
A
uto/All
Laserflash
Ltd. Acces
s
Set Default
Backlight
Buzzer
TC-J/TC-K
NTC/TC
Time/Date
Photoflash
O
N
Open the battery compart-
ment and set the switches
ON or Off according to the
desired probe type.
NTC - thermistor
TC - thermocouple
Thermocouple type J
Thermocouple type K
Connect the probe to the input.
The input is located at the bot-
tom of the handle behind the
ru
b
ber cover.
Press MODE, until the desired
probe symbol (TC-K shown
here) appears. The probe
temperature is shown in the
lower part of the display. The
real time infrared temperature is
shown in the main display.
back to
Mode
bu
tton
