33
576
Specifications of the Camera
Maximum Picture Number
640x480 Pixels (VGA)
26
Maximum Picture Number
320x240 Pixels (1/4 VGA)
100
Recharge Time for Flash approx. 5 sec
Useful Flash Range:
Standard Focus
Close Focus
0.5 to 2 m (19 to 79 in.)
0.2 to 1 m ( 8 to 40 in)
Camera Lens 6 mm (app. equal to 42 mm on a
35 mm camera)
Focal Points 200 mm (8 in.)(Close-up)
Infinity (Far Distance)
Light Sensitivity 6 lux
Shutter Speed variable, max. 1/15 sec
Data Interface USB 1.1
Image File Format JPG
