Your Life, our Quality. Worldwide. Residential

The contents of this publication must not be regarded as binding. EBARA Pumps Europe S.p.A. reserves the right to effect any modification it deems necessary, without prior notice.

S

elf-priming electric pumps in AISI 304 stainless steel.

APPLICATIONS

• Supply of drinking water

•

Domestic pressure boosting

• Small-scale garden irrigation

• Maximum working pressure: 6 bar

• Maximum temperature of the liquid: 45°C

• Maximum suction depth: 8 m

• G1 suction connection for JES, G1¼ for JE

• G1 discharge connection

MOTOR TECHNICAL DATA

• High efficiency motors IE2 starting from 0,75kW

• 2 poles self-ventilated closed asynchronous motor with internal

ventilation

• Class of insulation F

MATERIALS

• Pump body, motor bracket, seal housing disc, motor case and

fan cover in AISI 304

• AISI 303 shaft (part in contact with the liquid)

• Impeller in AISI 304 for JE, in PPE reinforce

ACCESSORIES (on request)

• 5 litre 10 bar ¾ EPDM vessel

• 24 litre 8 bar 1” EPDM vessel

• 24 litre 10 bar 1” EPDM vessel

• PVC 5m key float with counter-weight

power 2.2 kW - 3 HP)

PERFORMANCE CURVES (according to ISO 9906 Attachment A)

JE IDENTIFICATION CODE

JE M

SINGLE PHASE

POWER HPX100

M

ODEL

JES IDENTIFICATION CODE

100

120

150
