Your Life, our Quality. Worldwide. Residential

The contents of this publication must not be regarded as binding. EBARA Pumps Europe S.p.A. reserves the right to effect any modification it deems necessary, without prior notice.

S

elf-priming electric pumps in AISI 304 stainless steel

APPLICATIONS

• Supply of drinking water

•

Domestic pressure boosting

• Small-scale garden irrigation

PUMP TECHNICAL DATA

• Maximum working pressure: 6 bar

• Maximum temperature of the liquid: 45°C

• Maximum suction depth: 8 m

• G1 suction connection for JESX, G1¼ for JEX

• G1 discharge connection

MOTOR TECHNICAL DATA

• High efficiency IE2 motors starting from 0,75kW

• Self-ventilated 2 poles asynchronous motor

• Class of insulation F

MATERIALS

• Pump casing and seal housing disc in AISI 304

• AISI 303 shaft (part in contact with the liquid)

• Impeller in AISI 304 for JEX, in PPE reinforced with fibreglass for JESX

• Mechanical seal in Carbon/Ceramic/NBR

• Bracket and motor casing in aluminium

CONTROL PANELS

• 1EPBH

ACCESSORIES (on request)

• 5 litre 10 bar ¾ EPDM vessel

• Presscomfort - Pressure regulator

• Press•o•Matic - Variable speed control system

(230V±10% single phase - power supply three phase 220V output –

maximum motor power 2.2 kW - 3 HP)

PERFORMANCE CURVES (

according to ISO 9906 Attachment A)

JEX IDENTIFICATION CODE

JE X

MOTOR FRAME IN ALUMINIUM

POWER HPX100

MODEL

80

100

120

M
