101
Q2511 DSC200100L TRANSISTOR 1
Q2512 DSC200100L TRANSISTOR 1
Q3100 B1AAFB000002 TRANSISTOR 1 PAVCCZ
Q3101 B1AAFB000002 TRANSISTOR 1 PAVCCZ
Q3102 DSC200100L TRANSISTOR 1
Q3103 DSC200100L TRANSISTOR 1
Q3104 DSC200100L TRANSISTOR 1
Q3105 DSC200100L TRANSISTOR 1
Q4512 B1HFCFA00026 TRANSISTOR 1
Q4513 DSA200100L TRANSISTOR 1
Q4700 DSC200100L TRANSISTOR 1
Q4702 DSC200100L TRANSISTOR 1
Q5000 DSC200100L TRANSISTOR 1
Q5051 DSA200100L TRANSISTOR 1
Q5100 DSC2001S0L TRANSISTOR 1
Q5101 DSC200100L TRANSISTOR 1
Q5471 DSA200100L TRANSISTOR 1
Q5472 DSC2001S0L TRANSISTOR 1
Q5600 B1MBDDA00003 FET 1
Q5601 B1MBEDA00015 FET 1
Q5602 DSC2001S0L TRANSISTOR 1
Q5603 DSC2001S0L TRANSISTOR 1
Q5604 B1MBDDA00003 FET 1
Q5605 B1MBEDA00015 FET 1
Q8400 DSC200100L TRANSISTOR 1
Q8401 DSC200100L TRANSISTOR 1
Q9900 DSC200100L TRANSISTOR 1
Q9901 DSC200100L TRANSISTOR 1
R0900 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0901 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0902 EXB28V680JX RESISTOR ARRAY 1
R0903 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0905 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R0910 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R0911 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R0912 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R0913 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R0940 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0941 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0942 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0943 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0944 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0945 D0GA680JA015 M 68 OHM,
J,0.063W
1
R0948 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R0949 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R0957 ERJ2GEJ102X M 1K OHM J 1/4W 1
R0966 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R0967 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R0980 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R0981 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R0982 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R0983 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R0984 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R0985 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R1179 D1BB7151A055 M7.15KOHM, 1/10W 1
R1180 ERJ2GEJ102X M 1K OHM J 1/4W 1
R1181 D0GA473JA015 M 47KOHM,
J,0.063W
1
R1183 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R1185 D0GA101JA015 M 100 OHM,
J,0.063W
1
R1186 D0GA473JA015 M 47KOHM,
J,0.063W
1
R1187 D0GA273JA015 M 27K OHM J
,0.063W
1
R1503 D0GA473JA015 M 47KOHM,
J,0.063W
1
R1518 D0GA683JA015 M 68KOHM,
J,0.063W
1
R1519 D0GA473JA015 M 47KOHM,
J,0.063W
1
R1520 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R1521 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R1552 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R1562 D0GA473JA015 M 47KOHM,
J,0.063W
1
R1563 D0GA473JA015 M 47KOHM,
J,0.063W
1
R2053 D1BB1403A055 M 140KOHM, 1/10W 1
R2055 D1BB1403A055 M 140KOHM, 1/10W 1
R2069 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2070 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2101 D0GA332JA015 M 3.3KOHM,
J,0.063W
1
R2102 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R2103 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R2104 D0GA122JA015 M 1.2KOHM,
J,0.063W
1
R2110 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R2121 D0GA681JA015 M680 OHM,
J,0.063W
1
R2135 ERJ2GEJ102X M 1K OHM J 1/4W 1
R2139 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R2254 D0GA101JA015 M 100 OHM,
J,0.063W
1
R2255 D0GA473JA015 M 47KOHM,
J,0.063W
1
R2256 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2257 D0GA105JA015 M 1M OHM,
J,0.063W
1
R2258 D0GA101JA015 M 100 OHM,
J,0.063W
1
R2259 D0GA101JA015 M 100 OHM,
J,0.063W
1
R2260 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2263 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2264 D0GA101JA015 M 100 OHM,
J,0.063W
1
R2301 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2302 EXB28V220J RESISTOR ARRAY 1
R2304 D0GA473JA015 M 47KOHM,
J,0.063W
1
R2307 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R2308 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R2309 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
