102
R2310 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R2318 ERJ8GEYJ3R3V M 3.3 OHM, J,1/
8W
1
R2319 ERJ8GEYJ3R3V M 3.3 OHM, J,1/
8W
1
R2320 ERJ8GEYJ3R3V M 3.3 OHM, J,1/
8W
1
R2321 ERJ8GEYJ3R3V M 3.3 OHM, J,1/
8W
1
R2330 D0GAR00Z0001 C 0 OHM, 0.063W 1
R2331 D0GAR00Z0001 C 0 OHM, 0.063W 1
R2510 ERJ3GEYJ470 M 47 OHM,J,1/16W 1
R2511 D0GB104JA041 M 100KOHM J 1/
10W
1
R2512 D0GB224JA041 M 2.2KOHM,J,1/
10W
1
R2513 ERJ3GEYJ223 M 22KOHM,J,1/16W 1
R2514 D0GB103JA057 M 10K OHM J 1/
10W
1
R2515 D0GB473JA057 M 47KOHM,J,1/10W 1
R2516 D1BB6800A055 M 680 OHM, 1/10W 1
R2517 ERJ3GEYJ223 M 22KOHM,J,1/16W 1
R2518 D0GB473JA057 M 47KOHM,J,1/10W 1
R2519 D1BB1821A055 M1.82KOHM, 1/10W 1
R2750 D0GA101JA015 M 100 OHM,
J,0.063W
1
R2753 D0GB103JA057 M 10K OHM J 1/
10W
1
R2816 D0GA473JA015 M 47KOHM,
J,0.063W
1
R2820 D0GA101JA015 M 100 OHM,
J,0.063W
1
R2823 D0GA473JA015 M 47KOHM,
J,0.063W
1
R2870 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R2871 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2872 D1BA1501A014 M 1.5KOHM,
0.063W
1 PAVCCZ
R2873 D1BA1002A014 M 10KOHM, 0.063W 1
R2875 D0GA390JA015 M 39 OHM,
J,0.063W
1
R2879 D1BA1803A014 M 18KOHM, 0.063W 1
R2880 D1BB1432A055 M14.3KOHM, 1/10W 1
R2881 D1BB6651A055 M6.65KOHM, 1/10W 1
R2882 D1BB7151A055 M7.15KOHM, 1/10W 1
R2883 D1BB1741A055 M 1.74KOHM, 1/
16W
1
R2914 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R2918 D0GAR00Z0001 C 0 OHM, 0.063W 1
R2926 D0GA680JA015 M 68 OHM,
J,0.063W
1
R3003 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3012 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3013 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3014 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3108 D0GA101JA015 M 100 OHM,
J,0.063W
1
R3120 EXB28V221J RESISTOR ARRAY 1
R3128 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3129 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3130 ERJ6RED750 M 75 OHM, 1/10W 1
R3131 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3132 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3133 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3134 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3135 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3136 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3137 ERJ6RED750 M 75 OHM, 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R3138 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3139 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3140 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3141 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3142 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3143 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3144 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3145 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3146 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3147 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3150 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3151 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3152 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3153 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R3154 EXB28V221J RESISTOR ARRAY 1
R3157 EXB28V221J RESISTOR ARRAY 1
R3161 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3162 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3163 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3164 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3165 D0GA333JA015 M
33KOHM,J,0.063W
1
R3166 D0GA333JA015 M
33KOHM,J,0.063W
1
R3167 D0GA333JA015 M
33KOHM,J,0.063W
1
R3168 D0GA333JA015 M
33KOHM,J,0.063W
1
R3169 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R3170 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R3171 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R3172 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R3173 EXB28V221J RESISTOR ARRAY 1
R3177 EXB28V331J RESISTOR ARRAY 1
R3181 ERJ6RED750 M 75 OHM, 1/10W 1
R3182 ERJ6RED750 M 75 OHM, 1/10W 1
R3183 ERJ6RED750 M 75 OHM, 1/10W 1
R3184 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3185 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R3186 D0GA333JA015 M
33KOHM,J,0.063W
1
R3187 D0GA333JA015 M
33KOHM,J,0.063W
1
R3190 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R3191 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R3192 EXB28V820JX RESISTOR ARRAY 1
R3194 D0GA331JA015 M 330 OHM,
J,0.063W
1
R3195 D0GA331JA015 M 330 OHM,
J,0.063W
1
R3197 D0GA680JA015 M 68 OHM,
J,0.063W
1
R3198 D0GA680JA015 M 68 OHM,
J,0.063W
1
R3199 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3200 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3201 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3202 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3203 D1BA2152A014 M21.5KOHM,
0.063W
1 PAVCCZ
R3204 D1BA2152A014 M21.5KOHM,
0.063W
1 PAVCCZ
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
