103
R3205 D1BA1302A014 M 13KOHM, 0.063W 1 PAVCCZ
R3206 D1BA1302A014 M 13KOHM, 0.063W 1 PAVCCZ
R3207 D0GA273JA015 M 27K OHM J
,0.063W
1
R3208 D0GA273JA015 M 27K OHM J
,0.063W
1
R3209 D0GA680JA015 M 68 OHM,
J,0.063W
1
R3210 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R3211 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R3212 D0GA680JA015 M 68 OHM,
J,0.063W
1
R3221 ERJ6ENF1500 M 150 OHM, 1/10W 1
R3222 ERJ6ENF1500 M 150 OHM, 1/10W 1
R4003 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4004 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4005 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4006 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4011 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4548 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R4549 D0GA151JA015 M 150 OHM,
J,0.063W
1
R4550 D0GA151JA015 M 150 OHM,
J,0.063W
1
R4551 D0GA151JA015 M 150 OHM,
J,0.063W
1
R4552 D0GA560JA015 M 56 OHM,
J,0.063W
1
R4553 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4554 ERJ2GEJ102X M 1K OHM J 1/4W 1
R4556 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4560 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4651 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R4655 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R4659 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R4663 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R4666 D0GA330JA015 M 33 OHM,
J,0.063W
1
R4668 D0GA330JA015 M 33 OHM,
J,0.063W
1
R4670 D0GA330JA015 M 33 OHM,
J,0.063W
1
R4672 D0GA330JA015 M 33 OHM,
J,0.063W
1
R4676 ERJ2GEJ102X M 1K OHM J 1/4W 1
R4677 D0GA122JA015 M 1.2KOHM,
J,0.063W
1
R4702 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4703 D0GA330JA015 M 33 OHM,
J,0.063W
1
R4704 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4708 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4709 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4711 ERJ2GEJ102X M 1K OHM J 1/4W 1
R4712 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4715 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4716 D0GA330JA015 M 33 OHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R4717 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4721 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4722 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R4724 ERJ2GEJ102X M 1K OHM J 1/4W 1
R4725 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4739 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R4752 D0GA680JA015 M 68 OHM,
J,0.063W
1
R4753 D0GA680JA015 M 68 OHM,
J,0.063W
1
R4754 D0GA680JA015 M 68 OHM,
J,0.063W
1
R4755 D0GA680JA015 M 68 OHM,
J,0.063W
1
R4763 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R4764 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R4766 D0GA473JA015 M 47KOHM,
J,0.063W
1
R4767 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5005 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5006 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5007 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5008 D0GA822JA015 M8.2KOHM,
J,0.063W
1
R5050 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5051 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5052 D0GA105JA015 M 1M OHM,
J,0.063W
1
R5061 ERJ6GEYJ150V M 15 OHM,J,1/10W 1
R5065 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5100 D0GA273JA015 M 27K OHM J
,0.063W
1
R5101 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R5102 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R5103 D0GA683JA015 M 68KOHM,
J,0.063W
1
R5104 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5106 D0GA683JA015 M 68KOHM,
J,0.063W
1
R5110 D0GA101JA015 M 100 OHM,
J,0.063W
1
R5151 D0GA101JA015 M 100 OHM,
J,0.063W
1
R5152 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R5153 D0GA101JA015 M 100 OHM,
J,0.063W
1
R5154 D0GA470JA015 M 47 OHM,
J,0.063W
1
R5155 D0GA101JA015 M 100 OHM,
J,0.063W
1
R5471 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R5472 D0GA332JA015 M 3.3KOHM,
J,0.063W
1
R5473 ERJ2GEJ102X M 1K OHM J 1/4W 1
R5474 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5475 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R5479 ERJ6GEYJ471 M 470 OHM,J,1/
10W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
