104
R5481 ERJ2GEJ221 M 220 OHM,
J,0.063W
1
R5485 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R5486 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R5487 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5488 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5489 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5490 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5491 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5492 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5493 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5494 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R5600 D0GA680JA015 M 68 OHM,
J,0.063W
1
R5601 D1BB8200A087 M 820 OHM, 1/10W 1
R5602 D1BB2701A087 M 2.7KOHM, 1/10W 1
R5603 D1BB1241A087 M1.24KOHM, 1/10W 1
R5604 D1BB2001A087 M 2KOHM, 1/10W 1
R5605 D1BB2002A055 M 20KOHM, 1/10W 1
R5606 D1BB2402A055 M 24KOHM, 1/10W 1
R5607 D0GA223JA015 M 22K OHM J
0.063W
1
R5608 D0GA683JA015 M 68KOHM,
J,0.063W
1
R5609 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5610 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5611 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R5612 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5613 D0GA473JA015 M 47KOHM,
J,0.063W
1
R5616 D0GB100JA041 M 10 OHM J 1/10W 1
R5617 D0GB100JA041 M 10 OHM J 1/10W 1
R5618 D1BB3301A055 M 3.3KOHM, 1/10W 1
R5619 D1BB5601A055 M 5.6KOHM, 1/10W 1
R5620 D1BB1001A055 M 1KOHM, 1/10W 1
R5621 D1BB1001A055 M 1KOHM, 1/10W 1
R5622 D1BB2402A055 M 24KOHM, 1/10W 1
R5623 D1BB2202A055 M 22KOHM, 1/10W 1
R5626 D0GB100JA041 M 10 OHM J 1/10W 1
R5627 D0GB100JA041 M 10 OHM J 1/10W 1
R5640 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5641 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5642 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R5643 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R5644 D0GA752JA015 M7.5KOHM,
J,0.063W
1
R8002 D1BB2402A055 M 24KOHM, 1/10W 1
R8003 D1BB1002A055 M 10KOHM, 1/10W 1
R8004 D1BB2402A055 M 24KOHM, 1/10W 1
R8005 D1BA1001A014 M 1KOHM, 0.063W 1
R8006 D1BA1001A014 M 1KOHM, 0.063W 1
R8007 D0GA111JA015 M 110 OHM,
J,0.063W
1
R8008 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8009 D1BA56R0A014 M 56 OHM, 0.063W 1
R8010 D1BA3000A014 M 30 OHM. 0.063W 1
R8011 D0GB331JA041 M330 OHM J 1/10W 1
R8014 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8015 ERJ2GEJ102X M 1K OHM J 1/4W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R8017 D0GA471JA015 M 470OHM,
J,0.063W
1
R8031 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8032 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8211 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8212 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8300 EXB2HV680J RESISTOR ARRAY 1
R8301 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8302 D0GA471JA015 M 470OHM,
J,0.063W
1
R8303 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8305 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8306 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8310 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8315 D0GAR00Z0001 C 0 OHM, 0.063W 1
R8316 D0GAR00Z0001 C 0 OHM, 0.063W 1
R8322 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R8323 ERJ2GEJ220 M 22 OHM,
J,0.063W
1
R8324 D0GA561JA015 M 560OHM,
J,0.063W
1 PAVCCZ
R8325 D0GA561JA015 M 560OHM,
J,0.063W
1 PAVCCZ
R8326 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R8327 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R8393 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8394 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8395 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8396 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8397 EXB2HV103JV RESISTOR ARRAY 1
R8400 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8404 EXB2HV680J RESISTOR ARRAY 1
R8406 EXB28V680JX RESISTOR ARRAY 1
R8409 EXB28V680JX RESISTOR ARRAY 1
R8411 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8413 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8414 EXB28V151J RESISTOR ARRAY 1
R8415 EXB28V104JX RESISTOR ARRAY 1
R8416 EXB28V151J RESISTOR ARRAY 1
R8417 EXB28V104JX RESISTOR ARRAY 1
R8419 EXB2HV101J RESISTOR ARRAY 1
R8420 EXB2HV101J RESISTOR ARRAY 1
R8422 EXB2HV680J RESISTOR ARRAY 1
R8423 EXB2HV680J RESISTOR ARRAY 1
R8424 EXB28V680JX RESISTOR ARRAY 1
R8425 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8426 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8428 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8429 EXB28V473JX RESISTOR ARRAY 1
R8431 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8432 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8433 ERJ8RSJR10 M 1 OHM, 1/8W 1
R8434 D0GA473JA015 M 47KOHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
