105
R8436 D0GA223JA015 M 22K OHM J
0.063W
1
R8437 D0GA223JA015 M 22K OHM J
0.063W
1
R8438 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8439 D0GA223JA015 M 22K OHM J
0.063W
1
R8440 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R8441 D0GA681JA015 M680 OHM,
J,0.063W
1
R8445 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8447 D0GA151JA015 M 150 OHM,
J,0.063W
1
R8448 D0GA151JA015 M 150 OHM,
J,0.063W
1
R8449 D0GA151JA015 M 150 OHM,
J,0.063W
1
R8450 D0GA473JA015 M 47KOHM,
J,0.063W
1
R8451 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8452 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8453 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8454 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R8455 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R8456 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R8457 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8462 EXB28V680JX RESISTOR ARRAY 1
R8463 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8464 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8465 EXB28V680JX RESISTOR ARRAY 1
R8466 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8467 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8468 EXB2HV680J RESISTOR ARRAY 1
R8469 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8470 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8471 EXB28V103JX RESISTOR ARRAY 1
R8480 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8481 D0GA223JA015 M 22K OHM J
0.063W
1
R8483 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8484 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8485 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8488 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8489 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8490 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8491 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8492 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8493 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8494 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8495 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8496 D0GA680JA015 M 68 OHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R8497 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8498 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8499 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8500 EXB2HV103JV RESISTOR ARRAY 1
R8501 EXB28V680JX RESISTOR ARRAY 1
R8505 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8506 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8507 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8508 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8509 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8510 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8511 EXB28V103JX RESISTOR ARRAY 1
R8515 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8516 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8606 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8610 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8616 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8617 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8618 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8622 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8627 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8628 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8631 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8632 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8633 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8636 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8638 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8639 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8645 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8646 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8649 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8652 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8660 EXB2HV680J RESISTOR ARRAY 1
R8661 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8664 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8669 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8671 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8733 D1BB1600A055 M 160 OHM, 1/10W 1
R8824 D1BA6201A014 M6.2KOHM, 0.063W 1
R8856 D0GA473JA015 M 47KOHM,
J,0.063W
1
R8857 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8859 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8860 D0GA680JA015 M 68 OHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
