106
R8861 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8862 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8863 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8867 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8868 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8869 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8870 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8872 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8873 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8874 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8875 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8876 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8877 D0GA330JA015 M 33 OHM,
J,0.063W
1
R8878 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8879 EXB28V103JX RESISTOR ARRAY 1
R8890 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R8900 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8918 EXB2HV680J RESISTOR ARRAY 1
R8919 EXB2HV680J RESISTOR ARRAY 1
R8920 D0GA222JA015 M 2.2KOHM,
J,0.063W
1
R8922 EXB2HVR000 RESISTOR ARRAY 1
R8923 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8924 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8925 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8926 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8927 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8928 D0GA680JA015 M 68 OHM,
J,0.063W
1
R8950 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R9014 D1BB5601A055 M 5.6KOHM, 1/10W 1
R9016 D0GA2R2JA014 M 2.2OHM,
J,0.063W
1
R9017 D1BB4701A055 M 4.7KOHM, 1/10W 1
R9019 D0GA2R2JA014 M 2.2OHM,
J,0.063W
1
R9030 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R9031 ERJ6GEYJ331V M 330 OHM J 1/
10W
1
R9035 D0GA332JA015 M 3.3KOHM,
J,0.063W
1
R9039 D0GA473JA015 M 47KOHM,
J,0.063W
1
R9040 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R9054 D0GAR00Z0001 C 0 OHM, 0.063W 1
R9058 D0GAR00Z0001 C 0 OHM, 0.063W 1
R9103 D0GA101JA015 M 100 OHM,
J,0.063W
1
R9104 D0GA101JA015 M 100 OHM,
J,0.063W
1
R9105 D0GA473JA015 M 47KOHM,
J,0.063W
1
R9107 D0GA332JA015 M 3.3KOHM,
J,0.063W
1
R9120 D0GA101JA015 M 100 OHM,
J,0.063W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R9145 D0GA101JA015 M 100 OHM,
J,0.063W
1
R9190 D0GA101JA015 M 100 OHM,
J,0.063W
1
R9191 D0GA101JA015 M 100 OHM,
J,0.063W
1
R9198 EXB28V101JX RESISTOR ARRAY 1
R9203 D0GA272JA015 M 2.7KOHM,
J,0.063W
1
R9205 D0GA333JA015 M
33KOHM,J,0.063W
1
R9206 D0GA563JA015 M 56KOHM,
J,0.063W
1
R9208 EXB2HV470JV RESISTOR ARRAY 1
R9209 EXB2HV470JV RESISTOR ARRAY 1
R9224 D0GA470JA015 M 47 OHM,
J,0.063W
1
R9226 D0GA470JA015 M 47 OHM,
J,0.063W
1
R9247 D0GA470JA015 M 47 OHM,
J,0.063W
1
R9318 ERJ2GEJ102X M 1K OHM J 1/4W 1
R9320 D0GA152JA015 M 1.5KOHM,
J,0.063W
1
R9321 D0GA105JA015 M 1M OHM,
J,0.063W
1
R9323 ERJ2GEJ102X M 1K OHM J 1/4W 1
R9324 D0GB162JA041 N 1.6KOHM J 1/
10W
1
R9325 D0GB162JA041 N 1.6KOHM J 1/
10W
1
R9326 D0GB162JA041 N 1.6KOHM J 1/
10W
1
R9327 D0GB162JA041 N 1.6KOHM J 1/
10W
1
R9400 EXB2HV103JV RESISTOR ARRAY 1
R9401 EXB2HV103JV RESISTOR ARRAY 1
R9402 EXB28V103JX RESISTOR ARRAY 1
R9608 EXB2HV470JV RESISTOR ARRAY 1
R9609 EXB2HV470JV RESISTOR ARRAY 1
R9610 EXB2HV470JV RESISTOR ARRAY 1
R9821 D0GA390JA015 M 39 OHM,
J,0.063W
1
R9872 D1BB3301A055 M 3.3KOHM, 1/10W 1
R9873 D1BB1002A055 M 10KOHM, 1/10W 1
R9874 D1BB2702A055 M 27KOHM, 1/10W 1
R9875 D1BB2002A055 M 20KOHM, 1/10W 1
R9877 D1BB4702A055 M 47KOHM, 1/10W 1
R9878 D1BB1002A055 M 10KOHM, 1/10W 1
R9879 D1BB1502A055 M 15KOHM, 1/10W 1
R9903 D0GA472JA015 M 4.7KOHM,
J,0.063W
1
R9904 ERJ2GEJ104 M 100KOHM,
J,0.063W
1
R9905 ERJ2GEJ103 M 10KOHM,
J,0.063W
1
R9907 D0GA101JA015 M 100 OHM,
J,0.063W
1
R9908 D1BB1202A055 M 12KOHM, 1/10W 1
R9909 D1BB2702A055 M 27KOHM, 1/10W 1
R9910 D1BB1002A055 M 10KOHM, 1/10W 1
R9920 D0GA390JA015 M 39 OHM,
J,0.063W
1
RM2510 B3RAD0000168 REMOTE SENSOR 1
S1B K1KA03BA0237 3P CONNECTOR 1
SN2510 B3JB00000078 IC 1 PAVCCZ
SW2500 K0F162B00002 SWITCH 1
SW5150 K0H1BA000445 SWITCH 1
SW5151 K0H1BA000445 SWITCH 1
SW5152 K0H1BA000445 SWITCH 1
SW5153 K0H1BA000445 SWITCH 1
SW5154 K0H1BA000445 SWITCH 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
