107
TU2901A ENG37F03KF TUNER 1 PAVCCZ
X8000 H0J245500101 CRYSTAL 1
X8001 H0J120500062 CRYSTAL 1
X8300 H0J410500001 CRYSTAL 1 PAVCCZ
X9300 H0J200500076 CRYSTAL 1
C10 K1MN20BA0231 20P CONNECTOR 1
C11 K1MY68BA0345 68P CONNECTOR 1
C20 K1MY20BA0345 20P CONNECTOR 1
C21 K1MY68BA0345 68P CONNECTOR 1
C23 K1KY08AA0719 8P CONNECTOR 1
C25 K1KA04BA0107 4P CONNECTOR 1
C16002 F1L2J562A022 C 5600UF, K,6.3V 1
C16012 F2A2T251A004 E 250UF, 220V 1
C16013 F2A2T251A004 E 250UF, 220V 1
C16018 F0C2E155A252 E 0.015UF, 250V 1
C16024 F1L2J332A022 C 3300UF, K,6.3V 1
C16041 F1H1H392A970 C 3900PF, K, 50V 1
C16071 F1L2J1020001 C 1000UF, K,6.3V 1
C16072 F1L2J1020001 C 1000UF, K,6.3V 1
C16091 F1L2J1020001 C 1000UF, K,6.3V 1
C16092 F1L2J1020001 C 1000UF, K,6.3V 1
C16101 F1L2J222A022 C 2200UF, K,6.3V 1
C16104 F1H1E470A130 C 47UF, K, 25V 1
C16105 F1H1E470A130 C 47UF, K, 25V 1
C16131 F1K1E475A134 C 4.7UF, Z, 25V 1
C16133 F1K1E475A134 C 4.7UF, Z, 25V 1
C16135 F1K1E105A029 C 1UF, Z, 25V 1
C16151 F1K1E105A029 C 1UF, Z, 25V 1
C16152 F1K1E475A134 C 4.7UF, Z, 25V 1
C16153 F1K1E475A134 C 4.7UF, Z, 25V 1
C16154 F1K1E475A134 C 4.7UF, Z, 25V 1
C16191 F1K1E475A134 C 4.7UF, Z, 25V 1
C16192 F1H1E104A129 C 0.1UF, 25V 1
C16193 EEUFC1E470 E 47UF, 25V 1
C16195 F1K1E105A029 C 1UF, Z, 25V 1
C16201 F0C2E405A252 E 0.040UF, 250V 1
C16202 F0C2E405A252 E 0.040UF, 250V 1
C16242 F1H1C105A145 C 0.01UF, K, 16V 1
C16243 F1H1H103A970 C 0.001UF, K,
50V
1
C16244 F1J1A106A087 C 0.010UF, K,
10V
1
C16251 F1H1C105A145 C 0.01UF, K, 16V 1
C16252 F1K1E105A029 C 1UF, Z, 25V 1
C16271 EEUFC1E221 E 220UF, 25V 1
C16280 F1K1E105A029 C 1UF, Z, 25V 1
C16285 F1H1H104A970 C 0.1UF, K, 50V 1
C16286 F1H1H104A970 C 0.1UF, K, 50V 1
C16287 F1H1H104A970 C 0.1UF, K, 50V 1
C16314 F2A2T251A004 E 250UF, 220V 1
C16315 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C16316 F1H1C104A143 C 0.1UF, K, 16V 1
C16317 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C16318 F1J1H104A835 C 0.10UF, 50V 1
C16319 F1J1H104A835 C 0.10UF, 50V 1
C16328 F2A2C221A195 E 2200UF, 160V 1
C16331 F0C2E105A252 E 0.010UF, 250V 1
C16401 F1L2J562A022 C 5600UF, K,6.3V 1
C16412 F2A2T251A004 E 250UF, 220V 1
C16413 F0C2E155A252 E 0.015UF, 250V 1
C16414 F2A2T251A004 E 250UF, 220V 1
C16417 F2A2T251A004 E 250UF, 220V 1
C16421 F1L2J562A022 C 5600UF, K,6.3V 1
C16441 F1H1H392A970 C 3900PF, K, 50V 1
C16451 F1H1H392A970 C 3900PF, K, 50V 1
C16460 F1E2J222A002 C 2200PF, 600V 1
C16461 F1L2J1020001 C 1000UF, K,6.3V 1
C16471 F1L2J1020001 C 1000UF, K,6.3V 1
C16472 F1K1E105A029 C 1UF, Z, 25V 1
C16481 F1L2J1020001 C 1000UF, K,6.3V 1
C16490 F1H1C105A145 C 0.01UF, K, 16V 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
C16491 F1L2J1020001 C 1000UF, K,6.3V 1
C16501 F1K1E105A029 C 1UF, Z, 25V 1
C16502 F1K1E475A134 C 4.7UF, Z, 25V 1
C16503 F2A1E471A102 E 470UF, 25V 1
C16504 F1K1E475A134 C 4.7UF, Z, 25V 1
C16505 F1K1E105A029 C 1UF, Z, 25V 1
C16521 F1K1E105A029 C 1UF, Z, 25V 1
C16522 F1K1E475A134 C 4.7UF, Z, 25V 1
C16523 F2A1E471A102 E 470UF, 25V 1
C16524 F1K1E475A134 C 4.7UF, Z, 25V 1
C16525 F1K1E475A134 C 4.7UF, Z, 25V 1
C16534 F1K1E105A029 C 1UF, Z, 25V 1
C16561 F1J1A106A087 C 0.010UF, K,
10V
1
C16562 F1H1C105A145 C 0.01UF, K, 16V 1
C16564 F1H1C105A145 C 0.01UF, K, 16V 1
C16565 F1H1H103A970 C 0.001UF, K,
50V
1
C16566 F1H1H103A970 C 0.001UF, K,
50V
1
C16581 F1K1E105A029 C 1UF, Z, 25V 1
C16582 F1H1C105A145 C 0.01UF, K, 16V 1
C16593 F1H1H102A971 C 1000PF, K, 50V 1
C16602 F1H1H220A971 C 22PF, K, 50V 1
C16603 F1K2J102A014 C 1000UF, K,6.3V 1
C16604 F1K2J102A014 C 1000UF, K,6.3V 1
C16608 F1H1H221A971 C 220UF, K, 50V 1
C16632 F0C2E405A252 E 0.040UF, 250V 1
C16633 F0C2E405A252 E 0.040UF, 250V 1
C16641 F1K2J222A014 C 2200UF, K,6.3V 1
C16642 F1L2J562A022 C 5600UF, K,6.3V 1
C16645 F1K2J102A014 C 1000UF, K,6.3V 1
C16646 F1K2J102A014 C 1000UF, K,6.3V 1
C16661 F1K2J102A038 C 1000UF, K,6.3V 1
C16662 F1K2J102A038 C 1000UF, K,6.3V 1
C16664 F1H1H820A971 C 82UF, 50V 1
C16665 F1H1H820A971 C 82UF, 50V 1
C16666 F1H1H820A971 C 82UF, 50V 1
C16668 F1H1H221A971 C 220UF, K, 50V 1
C16675 F1H1H391A971 C 391UF, 50V 1
C16684 F1H1H104A970 C 0.1UF, K, 50V 1
C16685 F1H1H104A970 C 0.1UF, K, 50V 1
C16691 F2A2C101A097 E 1000UF, 160V 1
C16692 F1H1H104A970 C 0.1UF, K, 50V 1
C16707 F1H1H220A971 C 22PF, K, 50V 1
C16708 F1H1H104A970 C 0.1UF, K, 50V 1
C16721 F2A1H820A115 E 82UF, 50V 1
C16723 F1K1E105A029 C 1UF, Z, 25V 1
C16724 F1K1E475A134 C 4.7UF, Z, 25V 1
C16753 F1K1E475A134 C 4.7UF, Z, 25V 1
C16755 F1K1E475A134 C 4.7UF, Z, 25V 1
C16756 F1K1E475A134 C 4.7UF, Z, 25V 1
C16771 F1H1C105A145 C 0.01UF, K, 16V 1
C16773 F1K1E105A029 C 1UF, Z, 25V 1
C16791 EEUFC1E221 E 220UF, 25V 1
C16793 EEUFC1E221 E 220UF, 25V 1
C16794 F1J1A106A087 C 0.010UF, K,
10V
1
C16795 F2A1E471A102 E 470UF, 25V 1
C16796 F2A1E471A102 E 470UF, 25V 1
C16797 F1H1H104A970 C 0.1UF, K, 50V 1
C16813 F2A2T221A009 E 220UF, 220V 1
C16842 F2A2C101A097 E 1000UF, 160V 1
C16843 F1J1H104A835 C 0.10UF, 50V 1
C16844 F1J1H104A835 C 0.10UF, 50V 1
C16854 F1J1H104A835 C 0.10UF, 50V 1
C16856 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C16857 F1H1C104A143 C 0.1UF, K, 16V 1
C16858 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C16859 F1J1H104A835 C 0.10UF, 50V 1
C16860 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C16861 F1H1C104A143 C 0.1UF, K, 16V 1
C16862 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C16863 F1J1H104A835 C 0.10UF, 50V 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
