108
C16864 F1J1H104A835 C 0.10UF, 50V 1
C16891 F1K1E105A029 C 1UF, Z, 25V 1
C16902 F1E2J332A002 C 3300PF, 600V 1
C17101 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17103 F1H1C104A143 C 0.1UF, K, 16V 1
C17104 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17105 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17107 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17109 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17110 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17111 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17113 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17115 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17116 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17117 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17119 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17121 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17122 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17124 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17125 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17141 F1H1H101A971 C 100UF, 50V 1
C17202 F1H1C104A143 C 0.1UF, K, 16V 1
C17203 F1H1C104A143 C 0.1UF, K, 16V 1
C17205 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17206 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17207 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17209 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17210 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17212 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17213 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17215 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17217 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17218 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17219 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17221 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17223 F1L2A334A034 E 3300UF, 100V 1 PAVCCZ
C17224 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C17241 F1H1H101A971 C 100UF, 50V 1
CB1 K1MY55B00002 55P CONNECTOR 1
CB2 K1MY55B00002 55P CONNECTOR 1
CB3 K1MY55B00002 55P CONNECTOR 1
CB4 K1MY55B00002 55P CONNECTOR 1
CB5 K1MY55B00002 55P CONNECTOR 1
CB6 K1MY55B00002 55P CONNECTOR 1
CB7 K1MY55B00002 55P CONNECTOR 1
CB8 K1MY55B00002 55P CONNECTOR 1
CB9 K1MY55B00002 55P CONNECTOR 1
CB10 K1MY55B00002 55P CONNECTOR 1
CB11 K1MY55B00002 55P CONNECTOR 1
CB12 K1MY55B00002 55P CONNECTOR 1
CB13 K1MY55B00002 55P CONNECTOR 1
CB14 K1MY55B00002 55P CONNECTOR 1
CB15 K1MY55B00002 55P CONNECTOR 1
D16001 B0FCCN000003 DIODE 1 PAVCCZ
D16021 B0FCCN000003 DIODE 1 PAVCCZ
D16022 B0FCCN000003 DIODE 1 PAVCCZ
D16032 B0ACCJ000048 DIODE 1
D16041 B0FCCP000001 DIODE 1
D16050 B0ECKP000055 DIODE 1
D16051 B0FCCN000002 DIODE 1
D16101 B0JCME000093 DIODE 1
D16131 B0ECKP000055 DIODE 1
D16151 B0ECKP000055 DIODE 1
D16152 B0ECKP000055 DIODE 1
D16153 B0ECKP000055 DIODE 1
D16191 B0ECKP000055 DIODE 1
D16192 B0ACCJ000048 DIODE 1
D16196 DZ2J200M0L ZENER DIODE 1
D16253 B3ABB0000210 LED 1
D16255 B0ACCJ000048 DIODE 1
D16280 B0ACCJ000048 DIODE 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
D16281 DZ2J051M0L ZENER DIODE 1
D16282 DZ2J068M0L ZENER DIODE 1 PAVCCZ
D16285 B0ADEJ000035 ZENER DIODE 1
D16286 B0ACCJ000048 DIODE 1
D16315 DZ2J150M0L ZENER DIODE 1
D16316 B0ECKP000055 DIODE 1
D16317 B0ECKP000055 DIODE 1
D16401 DA3DF50ACSLW ZENER DIODE 1
D16402 DA3DF50ACSLW ZENER DIODE 1
D16407 B0JCME000093 DIODE 1
D16411 B0ACCJ000048 DIODE 1
D16422 B0FACP000005 DIODE 1
D16451 B0ECKP000055 DIODE 1
D16461 B0FACP000005 DIODE 1
D16466 B0ACCJ000048 DIODE 1
D16473 B0ACCJ000048 DIODE 1
D16474 B0ACCJ000048 DIODE 1
D16475 DZ2J051M0L ZENER DIODE 1
D16476 B0ACCJ000048 DIODE 1
D16477 DZ2J047L0L ZENER DIODE 1
D16478 B0ACCJ000048 DIODE 1
D16480 B0ACCJ000048 DIODE 1
D16482 B0FACP000005 DIODE 1
D16490 B0ECKP000055 DIODE 1
D16491 B0ECKP000055 DIODE 1
D16492 DZ2J047M0L ZENER DIODE 1
D16493 B0ADCJ000100 DIODE 1
D16494 B0ADCJ000100 DIODE 1
D16497 B0ECKP000055 DIODE 1
D16503 B0ECHR000001 DIODE 1
D16522 B0ECHR000001 DIODE 1
D16523 B0ECHR000001 DIODE 1
D16534 B0ECHR000001 DIODE 1
D16536 B0ECHR000001 DIODE 1
D16583 B3ABB0000210 LED 1
D16602 DZ2J150M0L ZENER DIODE 1
D16604 B0ADCJ000100 DIODE 1
D16605 DZ2J051L0L ZENER DIODE 1
D16607 B0ACCJ000048 DIODE 1
D16610 B0ACCJ000048 DIODE 1
D16618 B0ECKP000055 DIODE 1
D16641 B0FBCN000006 DIODE 1
D16642 B0FBCN000006 DIODE 1
D16645 DZ2J150M0L ZENER DIODE 1
D16646 DZ2J150M0L ZENER DIODE 1
D16647 DZ2J150M0L ZENER DIODE 1
D16648 DZ2J051L0L ZENER DIODE 1
D16649 B0ACCJ000048 DIODE 1
D16650 B0ACCJ000048 DIODE 1
D16651 DZ2J051M0L ZENER DIODE 1
D16652 B0ECKP000055 DIODE 1
D16653 B0ACCJ000048 DIODE 1
D16654 B0ACCJ000048 DIODE 1
D16662 DZ2J150M0L ZENER DIODE 1
D16663 DZ2J150M0L ZENER DIODE 1
D16664 DZ2J150M0L ZENER DIODE 1
D16669 B0ACCJ000048 DIODE 1
D16671 B0ACCJ000048 DIODE 1
D16673 B0ECHR000001 DIODE 1
D16674 B0ECHR000001 DIODE 1
D16677 B0ADEJ000035 ZENER DIODE 1
D16678 DZ2J15000L ZENER DIODE 1
D16702 B0ACCJ000048 DIODE 1
D16710 DZ2J15000L ZENER DIODE 1
D16711 B0ECHR000001 DIODE 1
D16712 DZ2J15000L ZENER DIODE 1
D16713 B0ECHR000001 DIODE 1
D16719 B0ECKP000055 DIODE 1
D16720 B0ECKP000055 DIODE 1
D16721 B0ECHR000001 DIODE 1
D16728 B0ECKP000055 DIODE 1
D16765 B0ECKP000055 DIODE 1
D16790 B0JCME000093 DIODE 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
