D16791 DZ2J200M0L ZENER DIODE 1
D16792 B0ACCJ000048 DIODE 1
D16820 B0ACCJ000048 DIODE 1
D16821 DZ2J330M0L ZENER DIODE 1
D16822 B0ADCJ000100 DIODE 1
D16824 DZ2J330M0L ZENER DIODE 1
D16825 DZ2J330M0L ZENER DIODE 1
D16859 B0HCKS000002 DIODE 1
D16871 DZ2J240M0L ZENER DIODE 1
D16872 DZ2J200M0L ZENER DIODE 1
D16874 DZ2J051M0L ZENER DIODE 1
D16875 B0ACCJ000048 DIODE 1
D16893 DZ2J056H0L ZENER DIODE 1
D16901 B0ADCJ000100 DIODE 1
D16902 B0ACCJ000048 DIODE 1
D16920 B0ADCJ000100 DIODE 1
IC16131 C0ZBZ0001707 IC 1
IC16151 C0ZBZ0001708 IC 1
IC16241 C0JBAU000043 IC 1
IC16251 C0BBBA000024 IC 1
IC16304 MIP3900MSSCF IC 1
IC16312 C0DBZMC00006 IC 1
IC16471 C0DBEYY00114 IC 1
IC16490 C0DBZMC00006 IC 1
IC16491 NJM2406F LINEAR IC 1
IC16501 C0ZBZ0001708 IC 1
IC16521 C0ZBZ0001708 IC 1
IC16561 C0JBAU000043 IC 1
IC16562 C0JBAU000043 IC 1
IC16563 C0JBAB000916 IC 1
IC16581 C0BBBA000024 IC 1
IC16661 C0BBBA000024 IC 1
IC16691 C0JBAC000363 IC 1
IC16692 C0DBZYY00352 IC 1
IC16724 C0CBADE00049 IC 1
IC16771 C0CBADC00072 IC 1
IC16773 C0JBAB000715 IC 1
IC16784 MIP3910MSSCF IC 1
IC16785 C0DBZYY00352 IC 1
IC16786 MIP3910MSSCF IC 1
IC16787 C0DBZYY00352 IC 1
IC16792 NJM2406F LINEAR IC 1
IC16793 C0DBZMC00006 IC 1
IC16920 C0BBBA000024 IC 1
IC17101 C0JBAU000043 IC 1
IC17201 C0JBAU000043 IC 1
IC17202 C0JBAZ002692 IC 1
L16002 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16003 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16011 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16012 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16303 G0C471MA0049 PEAKING COIL 1 PAVCCZ
L16401 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16403 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16411 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16412 G0C1R0K00014 PEAKING COIL 1 PAVCCZ
L16472 G0ZZ00002183 PEAKING COIL 1
L16698 G0C681MA0065 PEAKING COIL 1
L16851 G0ZZ00002183 PEAKING COIL 1
PC16191 B3PBA0000496 IC 1
PC16301 B3PBA0000498 IC 1
PC16461 B3PBE0000054 IC 1
PC16480 B3PBA0000498 IC 1
PC16603 B3PBA0000498 IC 1
PC16684 B3PBA0000496 IC 1
PC16685 B3PBA0000496 IC 1
PC16722 B3PBA0000498 IC 1
PC16723 B3PBA0000498 IC 1
PC16896 B3PBA0000498 IC 1
PC16897 B3PBA0000498 IC 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
Q16001 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16002 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16022 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16023 B1JBEN000002 TRANSISTOR 1 PAVCCZ
Q16041 B1JBEN000003 TRANSISTOR 1 PAVCCZ
Q16051 B1JBEN000003 TRANSISTOR 1 PAVCCZ
Q16055 B1HFPFA00001 TRANSISTOR 1
Q16056 B1HFPFA00001 TRANSISTOR 1
Q16101 B1CFRM000008 FET 1
Q16102 B1CFRM000008 FET 1
Q16141 B1HFPFA00001 TRANSISTOR 1
Q16161 B1HFPFA00001 TRANSISTOR 1
Q16191 B1HFPFA00001 TRANSISTOR 1
Q16251 B1ABCF000231 TRANSISTOR 1
Q16280 B1ABCF000231 TRANSISTOR 1
Q16401 DG3D5020CSLW TRANSISTOR 1
Q16402 DG3D5020CSLW TRANSISTOR 1
Q16421 B1JAEP000014 TRANSISTOR 1 PAVCCZ
Q16422 B1JAEP000014 TRANSISTOR 1 PAVCCZ
Q16441 B1JAEP000013 TRANSISTOR 1
Q16451 B1JAEP000012 TRANSISTOR 1
Q16471 B1ABCF000231 TRANSISTOR 1
Q16490 B1CBGD000001 FET 1
Q16501 B1HFPFA00001 TRANSISTOR 1
Q16521 B1HFPFA00001 TRANSISTOR 1
Q16531 B1HFPFA00001 TRANSISTOR 1
Q16551 B1HFPFA00001 TRANSISTOR 1
Q16601 B1CERR000042 FET 1
Q16602 DSC2001Q0L TRANSISTOR 1
Q16603 DSA2001S0L TRANSISTOR 1
Q16606 DSC2001Q0L TRANSISTOR 1
Q16607 B1CBGD000001 FET 1
Q16608 B1CBGD000001 FET 1
Q16621 B1JADN000005 TRANSISTOR 1 PAVCCZ
Q16645 DSC2001Q0L TRANSISTOR 1
Q16646 DSA2001S0L TRANSISTOR 1
Q16647 B1CBGD000001 FET 1
Q16649 B1ABCN000007 TRANSISTOR 1
Q16660 B1CERR000042 FET 1
Q16661 B1JAER000010 TRANSISTOR 1
Q16662 DSC2001Q0L TRANSISTOR 1
Q16663 DSA2001S0L TRANSISTOR 1
Q16668 DSC2001Q0L TRANSISTOR 1
Q16670 B1ADCN000007 TRANSISTOR 1
Q16671 B1ABCF000231 TRANSISTOR 1
Q16675 B1ADCN000007 TRANSISTOR 1
Q16676 B1ABCF000231 TRANSISTOR 1
Q16677 DSC2001Q0L TRANSISTOR 1
Q16678 B1ABCF000231 TRANSISTOR 1
Q16701 B1ADCN000007 TRANSISTOR 1
Q16702 B1ABCF000231 TRANSISTOR 1
Q16762 B1HFPFA00001 TRANSISTOR 1
Q16801 DSA2001S0L TRANSISTOR 1
Q16810 B1ABCF000231 TRANSISTOR 1
Q16815 B1ABCN000007 TRANSISTOR 1
Q16816 DSC2001Q0L TRANSISTOR 1
Q16817 DSC2001Q0L TRANSISTOR 1
Q16818 B1CBGD000001 FET 1
Q16876 B1ABCF000231 TRANSISTOR 1
Q16885 B1CFNG000001 FET 1
Q16920 B1ABCN000007 TRANSISTOR 1
Q16921 B1ABCN000007 TRANSISTOR 1
Q16930 DSC2001Q0L TRANSISTOR 1
Q16931 B1ABCN000007 TRANSISTOR 1
Q16932 DSC2001Q0L TRANSISTOR 1
R16001 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16002 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16022 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
