110
R16023 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16031 ERJ6ENF8202 M 82KOHM, 1/10W 1
R16032 ERJ6ENF8202 M 82KOHM, 1/10W 1
R16033 ERJ6ENF5602 M 56KOHM, 1/10W 1
R16034 ERJ6ENF2702 M 27KOHM, 1/10W 1
R16041 D0GF5R6JA047 M 5.6 OHM,J,
0.33W
1
R16051 D0GF5R6JA047 M 5.6 OHM,J,
0.33W
1
R16101 D0GD221JA059 M 220
OHM,F,0.25W
1
R16102 D0GD221JA059 M 220
OHM,F,0.25W
1
R16103 D0GD100JA059 M 10 OHM,J,0.25W 1
R16104 D0GD100JA059 M 10 OHM,J,0.25W 1
R16105 ERJ8GEYJ474 M 470KOHM, J,1/
8W
1
R16109 D0GD100JA059 M 10 OHM,J,0.25W 1
R16116 D0GB473JA057 M 47KOHM,J,1/10W 1
R16131 ERJ8GEYJ101V M 100 OHM, J,1/
8W
1
R16132 ERJ8GEYJ101V M 100 OHM, J,1/
8W
1
R16134 D0GD750JA059 M 75 OHM,J,0.25W 1
R16137 D0GF1R0JA047 M 1.0 OHM,J,
0.33W
1
R16141 D0GD100JA059 M 10 OHM,J,0.25W 1
R16143 D0GB473JA057 M 47KOHM,J,1/10W 1
R16151 ERJ3GEYJ101 M 100 OHM,J,1/
16W
1
R16152 ERJ3GEYJ101 M 100 OHM,J,1/
16W
1
R16154 D0GD750JA059 M 75 OHM,J,0.25W 1
R16155 D0GF1R0JA047 M 1.0 OHM,J,
0.33W
1
R16159 D0GF1R0JA047 M 1.0 OHM,J,
0.33W
1
R16161 D0GD100JA059 M 10 OHM,J,0.25W 1
R16163 D0GB473JA057 M 47KOHM,J,1/10W 1
R16171 D0GD100JA059 M 10 OHM,J,0.25W 1
R16173 D0GB473JA057 M 47KOHM,J,1/10W 1
R16181 D0GD100JA059 M 10 OHM,J,0.25W 1
R16183 D0GB473JA057 M 47KOHM,J,1/10W 1
R16191 ERJ6GEYJ151V M 150 OHM,J,1/
10W
1
R16192 D0GB103JA057 M 10K OHM J 1/
10W
1
R16193 ERJ6GEYJ750 M 75 OHM,J,1/10W 1
R16195 D0GF1R0JA047 M 1.0 OHM,J,
0.33W
1
R16230 ERJ6GEYJ470V M 47 OHM,J,1/10W 1
R16231 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16241 EXB38V470J RESISTOR ARRAY 1
R16242 EXB38V472JV RESISTOR ARRAY 1
R16251 D1BB1401A055 M 1.4KOHM, 1/10W 1
R16252 ERJ6ENF3902 M 39KOHM, 1/10W 1
R16253 ERJ6ENF3902 M 39KOHM, 1/10W 1
R16254 ERJ6ENF6801 M 6.8KOHM, 1/10W 1
R16255 D1BB1201A055 M 1.2KOHM, 1/10W 1
R16256 D1BB1501A055 M1.50KOHM, 1/10W 1
R16257 D0GB273JA041 M 27K OHM J 1/
10W
1
R16258 D0GB103JA057 M 10K OHM J 1/
10W
1
R16260 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R16280 D0GB222JA041 M 2.2KOHM,J,1/
10W
1
R16281 D0GB103JA057 M 10K OHM J 1/
10W
1
R16282 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R16283 D0GB473JA057 M 47KOHM,J,1/10W 1
R16284 D0GB224JA041 M 2.2KOHM,J,1/
10W
1
R16285 EXB38V623J RESISTOR ARRAY 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R16288 D0GF334JA047 M
330KOHM,F,0.33W
1
R16289 D0GF334JA047 M
330KOHM,F,0.33W
1
R16290 D0GF334JA047 M
330KOHM,F,0.33W
1
R16307 ERJ6RBD6492 M64.9KOHM,F,1/
10W
1
R16309 ERG1FJS333D M 33KOHM, J, 1W 1
R16318 ERJ6RBD683 M 68KOHM,J,1/10W 1
R16319 ERJ6RBD2491 M 2.49KOHM, 1/
10W
1
R16320 ERJ14YJ683 M 68KOHM, 1/2W 1
R16330 D0GB102JA041 M 1KOHM,J,1/10W 1
R16332 D0GB474JA041 M 470KOHM,J,1/
10W
1
R16334 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16335 D0GB102JA041 M 1KOHM,J,1/10W 1
R16401 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16402 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16410 D0GB391JA041 M 390 OHM,J,1/
10W
1
R16411 ERJ6ENF2700 M 270 OHM, 1/10W 1
R16416 D0GB103JA057 M 10K OHM J 1/
10W
1
R16417 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R16418 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R16421 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16422 D0GF7R5JA047 M 7.5 OHM,J,
0.33W
1
R16441 D0GF5R6JA047 M 5.6 OHM,J,
0.33W
1
R16451 D0GF5R6JA047 M 5.6 OHM,J,
0.33W
1
R16465 ERJ6ENF2702 M 27KOHM, 1/10W 1
R16466 ERJ6ENF5602 M 56KOHM, 1/10W 1
R16467 ERJ6ENF8202 M 82KOHM, 1/10W 1
R16468 ERJ6ENF8202 M 82KOHM, 1/10W 1
R16471 D0GB392JA041 M 3.9KOHM,J,1/
10W
1
R16472 D0GB222JA041 M 2.2KOHM,J,1/
10W
1
R16473 ERJ6GEYF561 M 560 OHM,F,1/
10W
1
R16474 D0GB102JA041 M 1KOHM,J,1/10W 1
R16475 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16476 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16478 D0GB562JA041 M 5.6KOHM,J,1/
10W
1
R16479 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R16490 ERJ6RED124 M 120KOHM, 1/10W 1
R16491 ERJ6RED124 M 120KOHM, 1/10W 1
R16492 ERJ6RED124 M 120KOHM, 1/10W 1
R16493 ERJ6RBD6191 M 6.19KOHM, 1/
10W
1
R16494 D1BB2001A055 M 2KOHM, 1/10W 1
R16495 ERJ6ENF7500 M 750 OHM, 1/10W 1
R16496 ERJ6GEYJ470V M 47 OHM,J,1/10W 1
R16497 D0GB473JA057 M 47KOHM,J,1/10W 1
R16498 D0GB103JA057 M 10K OHM J 1/
10W
1
R16503 D0GD100JA059 M 10 OHM,J,0.25W 1
R16504 D0GD750JA059 M 75 OHM,J,0.25W 1
R16506 D0GD100JA059 M 10 OHM,J,0.25W 1
R16509 D0GF1R0JA047 M 1.0 OHM,J,
0.33W
1
R16512 D0GB473JA057 M 47KOHM,J,1/10W 1
R16517 D0GB473JA057 M 47KOHM,J,1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
