111
R16521 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R16522 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R16523 D0GD750JA059 M 75 OHM,J,0.25W 1
R16531 D0GD100JA059 M 10 OHM,J,0.25W 1
R16533 D0GB473JA057 M 47KOHM,J,1/10W 1
R16534 D0GF5R6JA047 M 5.6 OHM,J,
0.33W
1
R16551 D0GD100JA059 M 10 OHM,J,0.25W 1
R16553 D0GB473JA057 M 47KOHM,J,1/10W 1
R16561 EXB38V470J RESISTOR ARRAY 1
R16562 EXB38V470J RESISTOR ARRAY 1
R16563 EXB38V470J RESISTOR ARRAY 1
R16564 EXB38V470J RESISTOR ARRAY 1
R16565 EXB38V472JV RESISTOR ARRAY 1
R16566 EXB38V472JV RESISTOR ARRAY 1
R16567 EXB38V472JV RESISTOR ARRAY 1
R16568 EXB38V472JV RESISTOR ARRAY 1
R16570 EXB38V472JV RESISTOR ARRAY 1
R16579 EXB38V470J RESISTOR ARRAY 1
R16580 D0GB562JA041 M 5.6KOHM,J,1/
10W
1
R16582 ERJ6ENF3902 M 39KOHM, 1/10W 1
R16583 ERJ6ENF3902 M 39KOHM, 1/10W 1
R16584 ERJ6ENF6801 M 6.8KOHM, 1/10W 1
R16585 D1BB1001A055 M 1KOHM, 1/10W 1
R16586 D1BB2151A055 M2.15KOHM, 1/10W 1
R16587 D0GB222JA041 M 2.2KOHM,J,1/
10W
1
R16588 D0GB103JA057 M 10K OHM J 1/
10W
1
R16590 ERJ3GEYJ221 M 220 OHM,J,1/
16W
1
R16591 EXB38V472JV RESISTOR ARRAY 1
R16593 D1BB1401A055 M 1.4KOHM, 1/10W 1
R16601 D0GF1R0JA047 M 1.0 OHM,J,
0.33W
1
R16604 ERJ6GEYJ331V M 330 OHM J 1/
10W
1
R16605 ERJ6GEYG182 M 1.8KOHM,J,1/
10W
1
R16607 D1BB6981A055 M6.98KOHM, 1/10W 1
R16609 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16610 D0GB104JA041 M 100KOHM J 1/
10W
1
R16612 D0GD470JA059 M 47 OHM,J,0.25W 1
R16615 D1BB1101A055 M 1.1 KOHM, 1/
10W
1
R16617 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R16621 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R16631 D0GB103JA057 M 10K OHM J 1/
10W
1
R16633 ERJ6GEYJ223 M 22KOHM,J,1/10W 1
R16634 ERJ6GEYJ471 M 470 OHM,J,1/
10W
1
R16645 D0GB562JA041 M 5.6KOHM,J,1/
10W
1
R16646 D1BB1181A055 M 1.18KOHM, 1/
10W
1
R16648 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16649 D0GD330JA059 M 33 OHM,F,0.25W 1
R16650 D0GB104JA041 M 100KOHM J 1/
10W
1
R16651 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16652 ERJ6GEYF822 M 8.2KOHM,F,1/
10W
1
R16653 ERJ8GEYJ182 M 1.8KOHM, J,1/
8W
1
R16654 ERJ6GEYJ470V M 47 OHM,J,1/10W 1
R16655 D0GB103JA057 M 10K OHM J 1/
10W
1
R16656 ERJ8GEYJ472V M 4.7KOHM, J,1/
8W
1
R16658 ERJ3RBD6341 M6.34 OHM, 1/13W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R16659 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R16660 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R16661 D0GB122JA041 N 1.2KOHM J 1/
10W
1
R16662 D1BB1002A087 M 10KOHM, 1/10W 1
R16663 ERJ6RBD7151 M 7.15KOHM, 1/
10W
1
R16664 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16665 D0GD330JA059 M 33 OHM,F,0.25W 1
R16666 D1BB2202A087 M 22KOHM, 1/10W 1
R16667 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16668 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16673 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R16674 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16675 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16677 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16678 D0GF202JA047 M 2KOHM,J, 0.33W 1
R16679 ERJ3RBD1072 M10.7KOHM, 1/13W 1
R16680 ERJ6GEYJ472V M 4.7K OHM J 1/
10W
1
R16681 D0GD100JA059 M 10 OHM,J,0.25W 1
R16684 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R16685 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R16686 D0GB103JA057 M 10K OHM J 1/
10W
1
R16687 D1BB2702A055 M 27KOHM, 1/10W 1
R16688 D1BB8871A055 M8.87KOHM, 1/10W 1
R16690 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16691 ERJ8GEYJ563 M 56KOHM, J,1/8W 1
R16692 ERJ6RBD152 M 1.5KOHM,J,1/
10W
1
R16694 ERJ8GEYJ563 M 56KOHM, J,1/8W 1
R16695 ERJ6RBD152 M 1.5KOHM,J,1/
10W
1
R16696 ERF5TK2R2 W 2.2 OHM, K, 5W 1
R16699 D0GB103JA057 M 10K OHM J 1/
10W
1
R16707 ERJ6GEYG392 M 3.9KOHM,J,1/
10W
1
R16711 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16712 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R16717 D0GB102JA041 M 1KOHM,J,1/10W 1
R16719 ERJ3GEYJ220 M 22 OHM,J,1/16W 1
R16721 EXB38V220JV RESISTOR ARRAY 1
R16742 D0GB473JA057 M 47KOHM,J,1/10W 1
R16745 D0GB474JA041 M 470KOHM,J,1/
10W
1
R16746 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R16747 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R16750 D0GD123JA059 M 12KOHM,F,0.25W 1
R16751 D0GD154JA059 M
150KOHM,F,0.25W
1
R16752 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16753 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R16755 D0GD123JA059 M 12KOHM,F,0.25W 1
R16756 D0GD123JA059 M 12KOHM,F,0.25W 1
R16761 D0GD100JA059 M 10 OHM,J,0.25W 1
R16763 D0GB473JA057 M 47KOHM,J,1/10W 1
R16765 D0GD100JA059 M 10 OHM,J,0.25W 1
R16769 D0GD750JA059 M 75 OHM,J,0.25W 1
R16772 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R16773 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R16774 ERG1SJ273 M 27KOHM, J, 1W 1
R16776 ERJ6GEYJ470V M 47 OHM,J,1/10W 1
R16783 D0GD154JA059 M
150KOHM,F,0.25W
1
R16785 ERJ6ENF1073 M 107KOHM, 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
