114
C301 ECKD3A101KBP C 100PF, K, 1KV 1
C302 F1BAF221A131 C 220UF, 250V 1
C314 ECWH8333HA P 0.033PF, J,
8KV
1
C400 ECJ1VB1H102K C 1000PF, K, 50V 1
C401 F1A3A221A039 E 220UF, 1KV 1
C402 F1H1C105A148 C 1UF, K, 16V 1
C403 F1J1E105A231 C 1 UF 25V 1
C406 F2A1H1000083 E 10UF, 50V 1
C407 ECWF6103HLB P 0.010UF,
J,600V
1
C410 ECQE6104KF P 0.1UF, K,630V 1
C411 ECJ2VB1H103K C 0.01UF, K, 50V 1
C412 ECJ1VB1H103K C 0.001UF, K,
50V
1
C413 ECJ1VB1H102K C 1000PF, K, 50V 1
C414 ECJ1VB1H103K C 0.001UF, K,
50V
1
C500 ECJ1VB1E104K C 0.10UF, K, 25V 1
C505 F2A1A681B345 E 680UF, 10V 1
C519 ECJ1VB1H102K C 1000PF, K, 50V 1
C601 ECJ1VB1H103K C 0.001UF, K,
50V
1
C603 ECJ1VB1H103K C 0.001UF, K,
50V
1
C607 ECJ1VB1H103K C 0.001UF, K,
50V
1
C616 ECJ1VB1H103K C 0.001UF, K,
50V
1
C617 ECJ1VB1H103K C 0.001UF, K,
50V
1
C623 F1J0J4750018 C 4.7UF, K, 16V 1
C625 ECJ1VB1H102K C 1000PF, K, 50V 1
C627 ECJ2VB1H103K C 0.01UF, K, 50V 1
C628 ECJ1VB1H103K C 0.001UF, K,
50V
1
C700 F1J1E105A231 C 1 UF 25V 1
C703 ECJ1VB1H332K C 3300PF, K, 50V 1
C706 F1H1C105A148 C 1UF, K, 16V 1
C707 F1J1E105A231 C 1 UF 25V 1
C709 F1J1E104A137 C 0.10UF, Z, 25V 1
C711 ECJ1VB1H102K C 1000PF, K, 50V 1
C712 F1J1H471A721 C 470PF, 50V 1
C713 F1J1E105A231 C 1 UF 25V 1
C714 F1J1H333A571 C 0.033UF, 50V 1
C715 F1J1H332A623 C 3300PF, 50V 1
C716 F1J1E105A231 C 1 UF 25V 1
C717 ECJ1VB1H103K C 0.001UF, K,
50V
1
C718 ECJ1VB1H102K C 1000PF, K, 50V 1
C720 F2BZZ1020005 ZZ 102UF 1
C724 ECJ1VB1H103K C 0.001UF, K,
50V
1
C725 ECJ1VB1H103K C 0.001UF, K,
50V
1
C726 F1J1H333A571 C 0.033UF, 50V 1
C727 ECJ1VB1E104K C 0.10UF, K, 25V 1
C728 ECJ1VB1E104K C 0.10UF, K, 25V 1
C800 F2A1E1020108 E 1000UF, 25V 1
C802 ECJ1VB1E104K C 0.10UF, K, 25V 1
C804 ECJ1VB1H103K C 0.001UF, K,
50V
1
C805 F1J1E105A231 C 1 UF 25V 1
C806 F2A1E1020108 E 1000UF, 25V 1
C807 F1J1E105A231 C 1 UF 25V 1
C808 ECJ1VB1E104K C 0.10UF, K, 25V 1
C810 F1J1E105A231 C 1 UF 25V 1
C901 F2BZZ1820005 ZZ 182UF 1
C902 F2A1H4700057 E 47UF, 50V 1
C903 F1J1H104A459 C 0.10UF, 50V 1
C905 ECJ2VB1H103K C 0.01UF, K, 50V 1
C906 F1H1H222A219 C 2200PF, K, 50V 1
C907 F1H1C105A148 C 1UF, K, 16V 1
C908 ECJ1VB1H102K C 1000PF, K, 50V 1
C909 F1J1H273A571 C 0.027UF, 50V 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
D100 B0FBAT000006 DIODE 1
D102 B0ACDD000001 DIODE 1
D103 B0BC01400033 ZENER DIODE 1
D104 B0JCME000093 DIODE 1
D106 B0EAKT000048 DIODE 1
D108 B0HAPR000016 DIODE 1
D109 B0HAPR000016 DIODE 1
D114 B0ACDJ000010 DIODE 1
D200 B0EBKT000007 DIODE 1
D201 MTZJ10B ZENER DIODE 1
D202 MTZJ10B ZENER DIODE 1
D205 MTZJ10B ZENER DIODE 1
D206 B0ACDJ000010 DIODE 1
D207 B0BB17000009 ZENER DIODE 1
D208 B0ECKM000046 DIODE 1
D209 B0ECKM000046 DIODE 1
D210 B0BA03300004 ZENER DIODE 1
D300 B0EAAD000001 DIODE 1
D301 B0EAAD000001 DIODE 1
D400 MTZJ10B ZENER DIODE 1
D401 MTZJ10B ZENER DIODE 1
D402 B0JCCC000002 DIODE 1
D404 MTZJ12B ZENER DIODE 1
D405 B0BA05100010 ZENER DIODE 1
D406 B0EAKS000003 DIODE 1
D408 B0ECKM000046 DIODE 1
D410 B0HAMP000067 DIODE 1
D411 B0BC8R100015 ZENER DIODE 1
D501 B0JAMG000031 DIODE 1
D600 B0ACDJ000010 DIODE 1
D604 B0EAAD000001 DIODE 1
D605 B0EAAD000001 DIODE 1
D611 B0ACDJ000010 DIODE 1
D701 B0ECKM000046 DIODE 1
D702 B0HBRR000001 DIODE 1
D703 B0FBAR000044 DIODE 1
D706 B0BC5R600065 ZENER DIODE 1
D708 B0ACDJ000010 DIODE 1
D800 B0FBBM000023 DIODE 1
D801 B0ACDJ000010 DIODE 1
D900 B0BA03600020 ZENER DIODE 1
D901 B0JCME000093 DIODE 1
D902 B0EAMR000015 DIODE 1
D903 B0BA02100001 ZENER DIODE 1
D904 B0BA02100001 ZENER DIODE 1
D905 B0BA03600020 ZENER DIODE 1
D907 B0EAMR000015 DIODE 1
D908 B0BA01500003 ZENER DIODE 1
F100 K5E802BZ0002 FUSE 1
F101 K5E802BZ0002 FUSE 1
F200 K5G631B00008 FUSE 1
IC100 C0DBZYY00361 IC 1
IC200 C0DBZMC00006 IC 1
IC201 MIP2K20MSSCF IC 1
IC202 B3PBA0000459 IC 1
IC400 MIP418AMDS IC 1
IC401 B3PBA0000459 IC 1
IC500 C0DBZMC00006 IC 1
IC600 B3PBA0000459 IC 1
IC601 B3PBA0000459 IC 1
IC602 C0EBH0000210 IC 1
IC603 C2ABDB000130 IC 1
IC700 LSSK0087 IC 1
IC701 C0DBZMC00006 IC 1
IC800 C0DBZMC00006 IC 1
IC901 C0DBZMC00006 IC 1
IC902 C0DBZYY00360 IC 1
IC903 B3PBA0000459 IC 1
IC904 C0DBZMC00006 IC 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
