115
L100 G0B103J00003 CHOKE COIL 1
L101 G0B103J00003 CHOKE COIL 1
L700 J0JCC0000119 CHIP INDUCTOR 1
P2 K1KY02BA0001 2P CONNECTOR 1
P6 K1KA11AA0082 11P CONNECTOR 1
P7 K1KA14AA0082 14P CONNECTOR 1
P9 K1KA02B00295 2P CONNECTOR 1
P11 K1KA03B00246 3P CONNECTOR 1
P25 K1KA10AA0082 10P CONNECTOR 1
P34 K1KA03AA0193 3P CONNECTOR 1
P35 K1KA03A00647 3P CONNECTOR 1
PR101 K5Y502B00008 FUSE 1
PR900 K5Y402B00006 FUSE 1
Q101 DSC5001R0L TRANSISTOR 1
Q103 B1BCCF000022 TRANSISTOR 1
Q104 B1CERR000045 FET 1
Q300 B1CHPD000008 FET 1
Q301 B1CHPD000008 FET 1
Q302 B1CERQ000059 FET 1
Q303 B1CERQ000059 FET 1
Q400 DSC5001R0L TRANSISTOR 1
Q401 B1CFGD000030 FET 1
Q402 B1CFGD000030 FET 1
Q505 B1CHPD000008 FET 1
Q600 DSC5001R0L TRANSISTOR 1
Q602 DSC5001R0L TRANSISTOR 1
Q701 B1HBCFA00033 TRANSISTOR 1
Q703 B1ADCF000111 TRANSISTOR 1
Q705 B1CFGD000030 FET 1
Q706 B1HDCEA00001 TRANSISTOR 1
Q707 DSC5001R0L TRANSISTOR 1
Q708 B1ADCF000111 TRANSISTOR 1
Q709 B1CFGD000030 FET 1
Q710 B1CFGD000030 FET 1
Q711 DSC5001R0L TRANSISTOR 1
Q712 DSC5001R0L TRANSISTOR 1
Q714 B1ADCF000116 TRANSISTOR 1
Q715 B1ADCF000116 TRANSISTOR 1
Q800 B1CHRD000028 TRANSISTOR 1
Q801 DSC5001R0L TRANSISTOR 1
Q805 B1ADCF000111 TRANSISTOR 1
Q806 DSC5001R0L TRANSISTOR 1
Q807 B1HBCFA00033 TRANSISTOR 1
Q901 B1CERQ000057 FET 1
R101 D0GB394JA057 M 390KOHM J 1/
10W
1
R102 ERF5TJ100 W 10 OHM, J, 5W 1
R103 ERJ6GEYJ333V M 33KOHM,J,1/10W 1
R104 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R105 D1AB6343A023 M 634 KOHM,
0.25W
1
R106 ERJ3GEYJ434 M 430KOHM,J,1/
16W
1
R107 D1AB6343A023 M 634 KOHM,
0.25W
1
R108 ERJ3GEYJ223 M 22KOHM,J,1/16W 1
R109 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R112 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R113 ERJ3EKF1002 M 10KOHM, 1/16W 1
R114 D0BF6R8JA035 M 6.8OHM,J,
0.05W
1
R115 D0BF6R8JA035 M 6.8OHM,J,
0.05W
1
R116 ERJ8GEYJ153 M 15KOHM, J,1/8W 1
R117 ERJ8GEYJ153 M 15KOHM, J,1/8W 1
R118 ERJ6GEYJ183V M 18KOHM,J,1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R119 D0GB103JA057 M 10K OHM J 1/
10W
1
R121 ERJ3GEYJ333 M 33KOHM,J,1/16W 1
R122 ERX12SJ4R7 M 4.7 OHM, J,1/
2W
1
R123 D0GB103JA057 M 10K OHM J 1/
10W
1
R125 D0XGR10J0003 M 0.100HM,J, 5W 1
R126 D0XGR10J0003 M 0.100HM,J, 5W 1
R127 ERJ6GEYJ331V M 330 OHM J 1/
10W
1
R128 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R129 D0GD4R7JA059 M 4.7
OHM,J,0.25W
1
R130 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R131 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R132 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R133 D1AB1004A023 M1000MOHM, 0.25W 1
R134 D1AB1004A023 M1000MOHM, 0.25W 1
R136 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R137 ERJ8GEYJ474 M 470KOHM, J,1/
8W
1
R138 ERJ6GEYJ123V M 12KOHM,J,1/10W 1
R139 ERJ6RBD123V M 12KOHM,J,1/10W 1
R141 EVMAASA00B23 CONTROL 2KOHMB 1
R147 D1AB8453A023 M 845 KOHM,
0.25W
1
R148 D1AB8453A023 M 845 KOHM,
0.25W
1
R150 ERJ6ENF9101 M 9.1KOHM, 1/10W 1
R200 D1AB3303A023 M330 KOHM, 0.25W 1
R201 D1AB3303A023 M330 KOHM, 0.25W 1
R203 D1AB3303A023 M330 KOHM, 0.25W 1
R204 D1AB3303A023 M330 KOHM, 0.25W 1
R206 ERJ6ENF3302 M 33KOHM, 1/10W 1
R207 ERJ6ENF1272 M12.7KOHM, 1/10W 1
R208 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R209 D0GB102JA057 M 1KOHM,J,1/10W 1
R210 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R211 ERJ6GEYJ224 M 220KOHM,J,1/
10W
1
R214 ERJ6GEYJ153V M 15KOHM,J,1/10W 1
R215 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R216 D0GD4R7JA059 M 4.7
OHM,J,0.25W
1
R217 D0GD4R7JA059 M 4.7
OHM,J,0.25W
1
R218 D0B1825JA033 M1.22MOHM,J,0.05
W
1
R300 D0GZ181JA020 M 180 OHM,J,
0.5W
1
R301 D0GZ181JA020 M 180 OHM,J,
0.5W
1
R302 ERJ8GEYJ220V M 22 OHM, J,1/8W 1
R303 ERJ8GEYJ220V M 22 OHM, J,1/8W 1
R304 D0CF240JA010 M 24 OHM, J,1/2W 1
R305 D0CF240JA010 M 24 OHM, J,1/2W 1
R400 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R401 ERJ6GEYJ203 M 20KOHM,J,1/10W 1
R403 ERJ6GEYJ302V M 3KOHM,J,1/10W 1
R404 ERG2SJW563 M 56KOHM, J, 2W 1
R405 D0GD4R7JA059 M 4.7
OHM,J,0.25W
1
R406 D0GD123JA059 M 12KOHM,F,0.25W 1
R407 ERG2SJW563 M 56KOHM, J, 2W 1
R408 D0GD123JA059 M 12KOHM,F,0.25W 1
R409 ERJ3GEYJ273 M 27KOHM,J,1/16W 1
R410 ERJ3GEYJ273 M 27KOHM,J,1/16W 1
R411 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R412 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R413 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
