116
R414 D0GB105JA057 M 1M OHM F 1/10W 1
R415 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R416 D1AB7503A023 M 750 KOHM,
0.25W
1
R417 D1AB6343A023 M 634 KOHM,
0.25W
1
R418 ERJ6ENF1003 M 100KOHM, 1/10W 1
R500 ERJ6GEYJ221V M 220 OHM,J,1/
10W
1
R502 ERJ3GEYJ332 M 3.3KOHM,J,1/
16W
1
R503 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R507 ERJ6RBD333 M 33KOHM,J,1/10W 1
R508 ERJ6RBD333 M 33KOHM,J,1/10W 1
R517 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R518 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R601 D0GB102JA057 M 1KOHM,J,1/10W 1
R602 ERJ3GEYJ224 M 220KOHM,J,1/
16W
1
R604 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R605 ERJ3GEYJ224 M 220KOHM,J,1/
16W
1
R608 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R609 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R610 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R611 ERJ3GEYJ101 M 100 OHM,J,1/
16W
1
R613 D0GB154JA057 M 150KOHM J 1/
10W
1
R615 D0GB182JA057 M 1.8KOHM J 1/
10W
1
R616 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R619 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R620 D0GB102JA057 M 1KOHM,J,1/10W 1
R622 D0GB102JA057 M 1KOHM,J,1/10W 1
R623 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R624 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R625 ERJ6ENF2701 M 2.7KOHM, 1/10W 1
R626 ERJ3EKF3302 M 33KOHM, 1/16W 1
R627 D0GB103JA057 M 10K OHM J 1/
10W
1
R628 ERJ3GEYJ222 M 2.2KOHM,J,1/
16W
1
R630 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R633 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R635 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R637 ERJ6RBD152 M 1.5KOHM,J,1/
10W
1
R639 ERJ3EKF10R0 M 10 OHM, 1/16W 1
R641 ERJ3GEYJ472 M 4.7KOHM,J,1/
16W
1
R643 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R644 ERJ8GEYJ330 M 33 OHM, J,1/8W 1
R645 ERJ3GEYJ333 M 33KOHM,J,1/16W 1
R646 D0GB102JA057 M 1KOHM,J,1/10W 1
R647 D0GB103JA057 M 10K OHM J 1/
10W
1
R649 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R652 ERJ6GEYG392 M 3.9KOHM,J,1/
10W
1
R653 ERJ6GEYG392 M 3.9KOHM,J,1/
10W
1
R661 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R662 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R663 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R700 D0GD4R7JA059 M 4.7
OHM,J,0.25W
1
R702 ERJ3GEYJ101 M 100 OHM,J,1/
16W
1
R703 ERJ6GEYG105 M 1.0 OHM,J,1/
10W
1
R704 ERJ6GEYJ100V M 10 OHM,J,1/10W 1
R706 ERJ8ENF1500 M 150 OHM, 1/8W 1
R707 ERJ3EKF2702V M27.0KOHM, 1/16W 1
R708 ERJ6GEYG681 M 680 OHM,J,1/
10W
1
R709 ERJ3EKF2202 M 22KOHM, 1/16W 1
R711 ERJ3EKF3302 M 33KOHM, 1/16W 1
R712 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R714 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R726 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R727 ERJ6ENF1201 M 1.2KOHM, 1/10W 1
R728 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R729 ERJ6GEYJ100V M 10 OHM,J,1/10W 1
R730 ERJ8GEYJ472V M 4.7KOHM, J,1/
8W
1
R731 ERJ6GEYJ4R7 M 4.7 OHM,J,1/
10W
1
R732 ERJ6ENF1802 M 18KOHM, 1/10W 1
R733 ERJ6GEYJ4R7 M 4.7 OHM,J,1/
10W
1
R734 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R736 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R739 ERJ6ENF3901 M 3.9KOHM, 1/10W 1
R740 ERJ3GEYJ331 M 330 OHM,J,1/
16W
1
R741 ERJ6ENF6201 M 6.2KOHM, 1/10W 1
R742 ERJ6ENF1003 M 100KOHM, 1/10W 1
R743 ERJ6ENF1002 M 10KOHM, 1/10W 1
R744 ERJ6ENF1001 M 1KOHM, 1/10W 1
R745 ERJ6GEYJ333V M 33KOHM,J,1/10W 1
R746 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R749 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R750 ERJ6ENF1002 M 10KOHM, 1/10W 1
R752 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R753 ERJ6ENF9102 M91.0KOHM, 1/10W 1
R754 ERJ6ENF9102 M91.0KOHM, 1/10W 1
R755 ERJ6ENF9102 M91.0KOHM, 1/10W 1
R756 ERJ6ENF9102 M91.0KOHM, 1/10W 1
R757 ERJ6ENF6802 M 68KOHM, 1/10W 1
R758 ERJ6ENF1503 M 150KOHM, 1/10W 1
R759 ERJ6ENF1503 M 150KOHM, 1/10W 1
R760 ERJ6ENF1503 M 150KOHM, 1/10W 1
R761 ERJ6ENF1503 M 150KOHM, 1/10W 1
R762 ERJ6ENF1603 M 160KOHM, 1/10W 1
R763 ERJ6ENF1502 M 15KOHM, 1/10W 1
R764 ERJ6ENF8201 M 8.2KOHM, 1/10W 1
R766 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R767 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R770 D0XGR01JA028 M 0.01OHM,J, 5W 1
R773 ERJ6ENF1802 M 18KOHM, 1/10W 1
R774 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R775 ERJ6ENF1802 M 18KOHM, 1/10W 1
R776 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R777 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R778 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R779 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R780 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R781 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R783 ERJ6ENF2003 M 200KOHM, 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
