117
R784 ERJ6ENF3303 M 330KOHM, 1/10W 1
R785 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R786 ERJ6GEYJ104V M 100KOHM,J,1/
10W
1
R787 ERJ3GEYJ331 M 330 OHM,J,1/
16W
1
R788 ERJ6GEYJ101V M 100 OHM,J,1/
10W
1
R789 ERJ3GEYJ334 M 330KOHM,J,1/
16W
1
R790 ERJ3EKF3301 M 3.3KOHM, 1/16W 1
R792 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R793 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R798 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R800 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R801 ERJ6GEYJ562V M 5.6KOHM,J,1/
10W
1
R802 ERJ3GEYJ431V M 430 OHM,J,1/
16W
1
R803 ERJ6RBD333 M 33KOHM,J,1/10W 1
R804 ERJ6RBD622 M 6.2KOHM,J,1/
10W
1
R807 ERJ3GEYD274V M 270KOHM,J,1/
16W
1
R808 D0GB102JA057 M 1KOHM,J,1/10W 1
R809 D0GB184JA057 M 180KOHM J 1/
10W
1
R810 D0GB473JA057 M 47KOHM,J,1/10W 1
R811 ERJ3GEYJ104 M 100KOHM,J,1/
16W
1
R812 ERJ6GEYJ103V M 10K OHM J 1/
10W
1
R900 ERJ8GEYJ222V M 2.2KOHM, J,1/
8W
1
R901 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R902 D0GF101JA047 M 100 OHM,J,
0.33W
1
R903 D0XGR05JA028 M 0.05OHM,J, 5W 1
R905 ERJ8GEYJ103 M 10KOHM, J,1/8W 1
R906 ERJ8GEYJ222V M 2.2KOHM, J,1/
8W
1
R907 ERJ6ENF3301 M 3.3KOHM, 1/10W 1
R908 ERJ6ENF3301 M 3.3KOHM, 1/10W 1
R909 D0GB473JA057 M 47KOHM,J,1/10W 1
R910 ERJ3GEYJ333 M 33KOHM,J,1/16W 1
R911 ERJ3GEYD153V M 15KOHM,J,1/16W 1
R912 ERJ6GEYJ331V M 330 OHM J 1/
10W
1
R913 ERJ6RBD152 M 1.5KOHM,J,1/
10W
1
R914 ERJ6GEYJ102V M 1K OHM J 1/10W 1
R915 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R916 ERJ6ENF1103 M 110KOHM, 1/10W 1
R917 ERJ6ENF1003 M 100KOHM, 1/10W 1
R918 ERJ6ENF8201 M 8.2KOHM, 1/10W 1
R919 ERJ6GEY0R00V M 0 OHM J 1/10W 1
R921 ERJ8GEYJ101V M 100 OHM, J,1/
8W
1
R922 ERX12SJ5R6 M 5.6 OHM, J,1/
2W
1
R923 EVMAASA00B23 CONTROL 2KOHMB 1
R924 ERJ8GEYJ103 M 10KOHM, J,1/8W 1
R926 ERJ6ENF2003 M 200KOHM, 1/10W 1
R927 ERJ6ENF2003 M 200KOHM, 1/10W 1
R928 ERJ6ENF2202 M 2.2KOHM, 1/10W 1
R933 ERJ8GEYJ101V M 100 OHM, J,1/
8W
1
R941 D0XGR10J0003 M 0.100HM,J, 5W 1
R942 ERJ6GEYJ222V M 2.2K OHM J 1/
10W
1
R943 ERJ6GEYJ223 M 22KOHM,J,1/10W 1
R944 ERJ6ENF1001 M 1KOHM, 1/10W 1
R945 ERJ6ENF9102 M91.0KOHM, 1/10W 1
R946 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R947 ERJ6GEYF473 M 47KOHM,J,1/10W 1
R948 ERJ6GEYJ223 M 22KOHM,J,1/10W 1
R949 ERJ6GEY0R00V M 0 OHM J 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
R950 ERJ6ENF4702 M 47KOHM, 1/10W 1
RL101 K6B1AYY00057 RELAY 1
RL102 K6B1AYY00057 RELAY 1
S102 J0LV00000011 SERGE ABSORBER 1
T100 G4DYA0000206 SWITCHING TRANS 1
T200 ETS15AC116AH SWITCHING TRANS-
FORMER
1
T300 G4DYA0000194 SWITCHING TRANS-
FORMER
1
T301 ETS42LZ1BGAD SWITCHING TRANS-
FORMER
1
T400 ETS29AZ2YGAD SWITCHING TRANS-
FORMER
1
T900 ETS28AU3KGAD SWITCHING TRANS-
FORMER
1
TP700 G0ZZ00002183 PEAKING COIL 1
TP900 G0ZZ00002183 PEAKING COIL 1
VR251 EVMAASA00B33 CONTROL 3KOHMB 1
X600 H2B400400021 CRYSTAL 1
Z1 K4CZ01000027 AV TERMINAL 1
Z2 K4CZ01000027 AV TERMINAL 1
Z3 K4CZ01000027 AV TERMINAL 1
ZN100 D4EAD6210001 VARISTOR 1
ZN101 D4EAB681A011 VARISTOR 1
ZN102 D4EAD6210001 VARISTOR 1
ZN200 D4EA8511A001 VARISTOR 1
ZN201 D4EA8511A001 VARISTOR 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
