Fluke 65 [4/12] Pushbuttons
![Fluke 65 [4/12] Pushbuttons](/views2/1005428/page4/bg4.png)
Model 65 English Instruction Sheet
Page
4
Pushbuttons
Pushbutton Description
G
Press and hold G to display the object’s surface
temperature. The thermometer clears any stored
maximum and minimum temperatures. The laser
pointer only activates if the laser switch is in the on
position.
While
G is pressed, the display shows HHHHH.
Release
G to stop measuring temperatures and
deactivate the laser. The display continues to show
the most recent temperature and
Cfor 20
seconds. Then the display turns off.
F
Press F to display the maximum measured
temperature. The display shows MAX.
Press
F a second time to display the minimum
measured temperature. The display shows MIN.
Press
F a third time to turn off this function.
E Press E and hold for 1 second to save the
displayed temperature. The display flashes TEMP
MEM 5 times to indicate that the operation is
successful.
Press
E to display a stored temperature. The
display shows TEMP MEM. Press
E again to
turn off this function.
D
Press D to switch between
o
C and
o
F.
Pressing any of the three top pushbuttons wakes up
the thermometer.
