English Instruction Sheet

Page 1

705

Loop Calibrator

Instruction Sheet

Introduction

The Fluke 705 Loop Calibrator is a source and measurement tool

for 0 to 20 mA or 4 to 20 mA current loop testing and a

measurement tool for dc voltage from 0 to 28 V. The calibrator

does not source and measure simultaneously.

Your calibrator is supplied with a set of TL75 test leads, AC72

alligator clips, 9 V installed alkaline battery, and this instruction

sheet.

Summary of Calibrator Capabilities

Function Range Resolution

dc V input +28 V 0.001 V

dc mA input 0 to 24 mA 0.001 mA

dc mA output

Loop power

output

24 V dc output N/A

Safety Information

Use the calibrator only as specified in this sheet, otherwise the

protection provided by the calibrator may be impaired.

A Warning identifies conditions and actions that pose hazard(s)

to the user; a Caution identifies conditions and actions that may

damage the calibrator or the equipment under test.
