English Instruction Sheet

Page 3

Pushbutton Functions

Button Function

Press to select source, simulate, or measure

modes.

Press while turning on the calibrator to select loop

power. The Loop symbol appears in the display.

Press simultaneously to start the SpanCheck

function. The

symbol appears in the

display. Output toggles between 0 % and 100 %.

Press to manually step the output up or down 25

Press both buttons simultaneously to select auto

ramp output. The

symbols appear in the

display.

Press to scroll the display up or down.

Press while turning on the calibrator to change and

save scroll steps to 0.001 mA.

Press while turning on the calibrator to toggle

between 0 to 20 mA and 4 to 20 mA and save the

current output span in a nonvolatile memory.

Using the Current Output Modes

The calibrator provides current output for calibrating and testing

0 to 20 mA and 4 to 20 mA current loops and instruments.

In source mode, the calibrator supplies the current. In simulate

mode, the calibrator simulates a two-wire transmitter in an

externally-powered current loop.
