English Instruction Sheet
Page 10
Measuring dc Volts
OFF
COM
+
705
LOOP CALIBRATOR
SOURCE
SIMULATE
MEASURE
VDC
SpanCheck
Loop Power
Measure
rt01f.eps
Maintenance
W
Warning
To avoid electric shock or personal injury:
• Do not allow water into the case.
• Remove any input signals prior to removing test
leads and opening case.
• When servicing the calibrator, use only specified
replacement parts.
For maintenance procedures not described in this sheet, contact
a Fluke Service Center.
