English Instruction Sheet
Page 9
Measuring dc mA with Loop Power
Loop power provides +24 V to power a transmitter and to read
loop current simultaneously. To exit, turn the calibrator off or
to V.
Two-wire
transmitter
OFF
COM
+
705
LOOP CALIBRATOR
SOURCE
SIMULATE
MEASURE
VDC
mA
SpanCheck
Loop Power
Measure
Press and hold while
turning on the calibrator
to mA.
+24 V output
rt06f.eps
