Model 65 English Instruction Sheet
Page
9
Setting the Switches
The switches enable the laser beam and display backlight. To
activate the laser, press
G. The factory settings are in the on
positions. The on position is to the right and the off position is to
the left.
Troubleshooting
Condition Solution
The laser will not activate.
If the display does not turn on or
shows
I, replace the battery.
If the display does not show
A,
turn on the laser switch.
The thermometer seems to be
giving incorrect readings.
Check for the conditions in
"Ensuring Accuracy" and "Cleaning
the Focal Lens."
The displayed temperature
fluctuates (but the surface
temperature remains
constant).
Leave the thermometer on until the
displayed temperature stabilizes.
(Some fluctuation is normal,
especially in the tenths digit.)
Calibration
Fluke recommends that you return the thermometer annually to a
Fluke Service Center for calibration, starting one year after
purchase.
