EN
77-2665-R13.2 (10/2015)6 / 8
Primer/surfaces 3-4 1-4
Light Stains, Inks 4-5 1-5
Acrylic Enamels 6-7 2-7
Lacquers 7-8 2-8
Low VOC, Urethanes 8-10 2-10
TYPE OF FLUID ATOMIZING FLUID PRESSURE
PSI RANGE- PSI
AIR PRESSURE RECOMMENDATIONS
HVLP AIR NOZZLES
Maximum recommended nozzle
atomizing pressure is 10 psi. The
95P and 905P air nozzles are most
suitable for conventional materials.
Use of very low fluid delivery rates
with these nozzles will produce a
narrower than normal fan pattern.
Use the 97P air nozzle for heavy
bodied, high solids materials and
low fluid rates with conventional
materials. High flow rates with light
bodied materials may result in some
minor “smoking” or fluid build-up
on the face of these nozzles.
HOW TO USE THE
NOZZLE SELECTION
CHART
HVLP AIR NOZZLES
95P, 97P, 95AS, 95AP, 97AP, 905P
HVLP AIR NOZZLE 92P
NOZZLE AIRFLOW
SCFM
SIDE PORT
CONTROL
REGULATOR*
PSI
REGULATOR*
PSI
GUN INLET
PSI
3.0 11.0 20.0 27.0
5.0 15.7 30.0 40.0
7.0 17.5 38.0 50.0
9.0 19.6 45.0 58.0
10.0 22.5 50.0 64.0
NOZZLE ATOMIZING
PSI
NOZZLE AIRFLOW
SCFM
SIDE PORT
CONTROL
3.0 4.5 6.0 9.0
5.0 6.0 8.5 10.0
7.0 6.8 11.0 14.0
9.0 7.5 13.5 18.0
10.0 8.0 15.0 19.0
* NOTE: Regulator pressures are based on 25' of 5/16" diameter hose in good condition without quick-disconnects or other restrictive fittings.
Use the air nozzle test gauge accessory to confirm the atomizing/regulator pressure relationship for your actual air supply set-up.
These recommendations are for “typical” or “average” fluids, and are intended to serve as a starting point. Adjust as necessary for
your specific application.
HVLP AIR NOZZLE 90P
HVLP AIR NOZZLE* 94P
NOZZLE ATOMIZING
PSI
NOZZLE AIRFLOW
SCFM
SIDE PORT
CONTROL
GUN INLET
PSI
3.0 4.0 5.0
5.0 4.5 7.0
7.0 5.0 10.0
9.0 5.5 12.0
10.0 6.0 15.0
Side Port
Nozzle Nozzle Control
Atomizing AIR FLOW GUN INLET
PSI SCFM PSI
3.0 7.0 14.0
5.0 9.0 21.0
7.0 11.0 27.0
9.0 12.0 30.0
10.0 13.0 33.0
NOZZLE ATOMIZING
PSI
NOZZLE AIRFLOW
SCFM
SIDE PORT
CONTROL
REGULATOR*
PSI
GUN INLET
PSI
3.0 5.5 8.0 10.0
5.0 7.0 11.5 14.0
7.0 8.0 14.5 18.0
9.0 9.5 17.0 22.5
10.0 10.0 18.0 24.0
HVLP AIR NOZZLE 93P
NOZZLE ATOMIZING
PSI
GUN INLET
PSI
AIR NOZZLES
HVLP AIR NOZZLE 100P
Gun Nozzle Nozzle
Inlet AIR FLOW Atomizing
PSI SCFM PSI
3.0 3.2 2
6.1 4.8 4
9.0 6.0 6
11.6 6.9 8
14.3 8.0 10
