5/10/15-GALLON GALVANIZED TANK ASSEMBLIES – SPECIFICATIONS & OPTIONS
SPECIFICATIONS
GALVANIZED TANKS
Maximum Working Pressure 110 psi
Tank Shell SA-414 Steel, Galvanized (Zinc)
Tank Lid SA-414 Steel, Galvanized (Zinc)
Fluid Tube 3/8 in. Steel Pipe, Galvanized
Fluid Outlet (Elbow) Steel, Zinc Plate
Fluid Valve, Outlet Brass, Nickel Plate 3/8-18 NPS(M)
Agitator Paddle/Propeller Nylon, Glass Filled
Agitator Shaft Steel, Zinc Plate
Agitator Shaft Seal Engineered PTFE, Stainless Steel
Air Manifold Steel, Zinc Plate
Plug (Air Manifold Coupling) Steel, Zinc Plate
Bottom Outlet (Optional Kit) 304 Stainless Steel 3/4-14 NPS(M)
AIR CONTROL OPTIONS
TYPE APPLICATION
No Regulation (Air inlet pressure gauge only)
Holding tanks, Transfer tanks, Used where precision fluid pressure control is
not required.
Standard Single Regulation
Provides standard fluid pressure control only. For use where precision control
of both fluid and air pressures is not required. Also Used where atomization
air can be taken from filter/regulator air lines.
Standard Double Regulation
Precision control for use with materials that are best applied at low, closely
controlled, fluid and atomization air pressures. Used with portable air
compressors or with air lines when no other means of air pressure regulation
is available.
Extra Sensitive Regulation Provides extremely accurate, low pressure, fluid pressure control
Extra Sensitive Regulation with
Standard Gun Regulation
Provides extremely accurate, low pressure, fluid pressure control plus precision
control of spray gun atomizing air.
AGITATION OPTIONS
TYPE APPLICATION
No Agitation
Materials that require minimal or no mixing and/or readily hold any solids in
suspension.
Gear-reduced Drive Agitation
Heavy-duty agitator for medium to high viscosity materials that require mixing
and/or solids suspension.
TANK CAPACITIES
Nominal Capacity Actual Capacity
5 US Gallons 9.8 US Gallons
10 US Gallons 11.8 US Gallons
15 US Gallons 19.8 US Gallons
