Binks 183S-1013-CE 40 л [6/12] 10 15 gallon galvanized tank assemblies
![Binks 183S-1013-CE 40 л [6/12] 10 15 gallon galvanized tank assemblies](/views2/1548049/page6/bg6.png)
6
1
2
3
2
5
15
8 9
16
12 or 12A
13
14
17
11
18
20
22
23
25
36
24
26
32
33
31
30
35
34
29
4
6
24
25
26
28
27
25
The Stationary
Paddle Kit (28)
comes standard
only on 10 and
15 gallon tanks.
The 5 and 10
gallon tanks come
standard with one
Agitator Paddle Kit
(26).
The 15 gallon
tanks come
standard with
two Agitator
Paddle Kits (26).
21
39
38
37
Agitator-Regulator Hook-Up with
Standard Regulation.
1 or 2 Regulators
Agitator-Regulator Hook-Up with
Extra Sensitive Regulation.
1 or 2 Regulators
Requires 40 PSI Safety Valve (12A).
12A
PG
7
10
PG
19
For bottom outlet
conversion, remove and
discard plug
PG
PETROLEUM
JELLY/GREASE
1¼" NPS
1¼" NPS
¾" NPT
Refer to SBBI-19-087
for information about
the drive unit.
5/10/15-GALLON GALVANIZED TANK ASSEMBLIES
Grounding Diagram
Purchase hardware locally
5/16–18 x 3/4 Long
Hex Head Bolt
(1 Required)
2X
5/16–18 Hex Head Nut
(2 Required)
Sufficient Length
12 Gauge Wire
(Not Shown)
5/16 Lock Washer
(1 Required)
Tank Skirt (Ref)
NOTE
Use PTFE based thread sealant on all
air and fluid connections.
CAUTION
Use 40 PSI Safety Valve (12A) with an
extra sensitive regulator.
!
NOTE
Open side of shaft seal (8)
faces downward.
Retainer (9) required only for
vacuum operation.
