7
5/10/15-GALLON GALVANIZED TANK ASSEMBLIES – PARTS LIST
ITEM
NO. PART NO. DESCRIPTION
5-GAL
QTY.
10-GAL
QTY.
15-GAL
QTY.
1
▲
QMS-46 RETAINING NUT 1 1 1
2
▲
QMG-85 THRUST WASHER 2 2 2
3
▲
----- THRUST COLLAR 1 1 1
4
▲•
----- SET SCREW (5/16-18 X 3/8) 1 1 1
5 QMS-447 THRUST COLLAR KIT (INCL 4 & 5) 1 1 1
6
▲
QMG-409 BEARING ASSY-PLAIN STEEL 1 1 1
7
▲
SSG-8184-K2 O-RING (KIT OF 2) 1 1 1
8
▲
----- SHAFT SEAL 5/8 I.D. 1 1 1
9
▲
----- INTERNAL RETAINING RING 1 1 1
10 KK-5042 SHAFT SEAL KIT (INCL 8 & 9) 1 1 1
11 QMG-19 PLUG (NON-AGITATED MODELS ONLY) 1 1 1
12 TIA-5110 SAFETY VALVE ASSY, 110 PSI 1 1 1
12A TIA-5040 SAFETY VALVE ASSY, 40 PSI (EXTRA SENSITIVE ONLY)
13 QMG-21 AIR MANIFOLD 1 1 1
14 SS-2707 AIR RELIEF VALVE 1/4 NPT(M) 1 1 1
15 83-524 FILL PORT CAP 1 1 1
16 83-1207 FILL PORT CAP GASKET 1 1 1
17 • ----- STREET ELBOW, 3/8-18 NPT (Brass) 1 1 1
18 VA-540 BALL VALVE, 3/8 NPS OUTLET 1 1 1
19 QMG-402-1 TANK LID 1 1 1
20 QM-1458-1 TANK GASKET 1 1 1
21 • ----- PLUG, 1/2-14 NPT (PLATED STEEL) 1 1 1
22 QMG-32 FLUID TUBE 1 ----- -----
22 QMG-33 FLUID TUBE ----- 1 -----
22 QMG-34 FLUID TUBE ----- ----- 1
23
▲
QMG-28 AGITATOR SHAFT 1 ----- -----
23
▲
QMG-29 AGITATOR SHAFT ----- 1 -----
23
▲
QMG-30 AGITATOR SHAFT ----- ----- 1
24
▲
----- AGITATOR PADDLE 1 1 2
25
▲•
----- SOC HEAD CAP SCREW, 5/16-18 X 1-1/4, S.S. 1 2 3
26 QMS-444 AGITATOR PADDLE KIT (INCL 24 & 25) 1 1 2
27
▲
----- STATIONARY PADDLE ----- 1 1
28 QMS-445 STATIONARY PADDLE KIT (INCL 25 & 27) ----- 1 1
29 PTL-408-K20 DISPOSABLE TANK LINER, 5-GAL 1 ----- -----
29 PTL-412-K8 DISPOSABLE TANK LINER, 10-GAL ----- 1 -----
29 PTL-415-K10 DISPOSABLE TANK LINER, 15-GAL ----- ----- 1
30 QM-1352 THUMB SCREW (SEE ITEM 34) 6 6 6
31 • ----- COTTER PIN, 1/8 DIA. X 1" LG. (SEE ITEM 34) 6 6 6
32 ----- CLEVIS PIN (SEE ITEM 34) 6 6 6
33 ----- CLAMP (SEE ITEM 34) 6 6 6
34 + KK-5014 CLAMP, PIN, & SCREW KIT 6 6 6
35 QMG-505-1 TANK & LUG ASSY, 5-GAL 1 ----- -----
35 QMG-510-1 TANK & LUG ASSY, 10-GAL ----- 1 -----
35 QMG-515-1 TANK & LUG ASSY, 15-GAL ----- ----- 1
36 ----- BOTTOM PLUG 1 1 1
37 HA-57011 AIR HOSE ASS'Y (INCL W/ ITEM 39) 1 1 1
38 SEE PAGES 8 & 9 AIR CONTROL 1 1 1
39 QS-5012 AIR MOTOR/GEARBOX DRIVE 1 1 1
• Purchase locally.
+ KK-5014 Clamp, Pin, and Screw Kit includes 1 each of items 30, 31, 32, and 33.
▲ Items available separately or as a complete agitator assembly:
QMG-418 (for 5 gallon tanks)
QMG-419 (for 10 gallon tanks)
QMG-420 (for 15 gallon tanks)
