715 English Instruction Sheet

Page 14

Specifications

Specifications are based on a one year calibration cycle and

apply from +18°C to +28°C unless stated otherwise. “Counts”

means number of increments or decrements of the least

significant digit.

DC V Input and Output

Range Resolution Accuracy,

±(% of Reading + Counts)

200 mV 0.01 mV 0.015% + 2

20 V output

25 V input

0.001 V 0.01% + 2

Input impedance: 1 M

Ω

(nominal), < 100 pF

Overvoltage protection: Fuseless

Voltage drive capability: 1 mA

DC mA Input

Range Resolution Accuracy,

±(% of Reading + Counts)

24 mA 0.001 mA 0.01% + 2

Overload protection: Fuseless

DC mA Output

Range: 0 mA to 24 mA

Percent display: 0% = 4 mA, 100% = 20 mA

Accuracy: ±(0.01% of reading + 2 counts)

Source mode:

Compliance: 1000 Ω at 20 mA for battery voltage ≥6.8 V (700 Ω

at 20 mA for battery voltage 5.8 to 6.8 V)

Simulate mode:

External loop voltage requirement: 24 V nominal, 30 V maximum,

12 V minimum

Loop Power

24 V ±10%
