English
Pressure Specifications (cont.)
Model Range SI Range Metric Max SI Max Metric
717-3000G (0-3000) PSI
20684 kpa or
20.7 mPa
6000 PSI
41369 kPa
or 41.4 mPa
717-5000G (0-5000) PSI
34474 kPa or
34.5 mPa
10000 PSI
68948 kPa
or 69 mPa
Accuracy: Pressure Accuracy is +/- 0.05% of range
Temperature coefficient:
0.01 % of range per °C for temperature ranges of between −10 °C to
18 °C and 28 °C to 55 °C.
Pressure Display, Pressure Module Input
Range Resolution Accuracy
Refer to the Instruction Sheet for the pressure module
DC mA Input
Range
Resolution
Accuracy,
± ( % of Reading + Counts)
24 mA 0.001 mA 0.015 + 2
Overload protection:
Fuseless overvoltage protection
Temperature coefficient:
0.005 % of range per °C for temperature ranges of between −10 °C to
18 °C and 28 °C to 55 °C.
Loop Supply
24 V dc nominal
General Specifications
Maximum voltage applied between either an mA terminal and earth ground or
between the mA terminals:
30 V
Storage temperature:
−40 °C to 60 °C
Operating temperature:
−10 °C to 55 °C
Operating altitude:
3000 meters maximum
Relative humidity:
95 % up to 30 °C;
75 % up to 40 °C;
45 % up to 50 °C;
35 % up to 55 °C
Vibration:
Random 2 g, 5 Hz to 500 Hz, per MIL -PRF_28800F, Class 2
Shock:
1 meter drop, per IEC 61010-1
