English
Safety Compliance:
IEC 61010-1 2nd Edition CAT I, 30 V;
Pollution Degree 2
CSA C22.2 No. 1010.1;
ANSI/ISA S82.02. Maximum Transient Overvoltage: 240 VAC for 10
Seconds.
CE:
Complies with EN 61326 Class A; EN61010-1
Protection Class: Class II, Double Insulated
Power requirements:
Single 9 V battery (ANSI/NEDA 1604A or IEC 6LR61)
Size:
34.9 mm H x 87 mm W x 187 mm L
(1.55 in H x 3.41 in W x 7.35 in L);
With holster and Flex-Stand: 52 mm H x 98 mm W x 201 mm L (2.06 in H x
3.86 in W x 7.93 in L)
Weight:
369 g (13 oz);
With holster and Flex-Stand: 624 g (22 oz)
Contacting Fluke
To contact Fluke for product information, operating assistance, service, or to get
the location of the nearest Fluke distributor or service center, call:
USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
Or visit Fluke's web site at: www.fluke.com
.
Register your Calibrator at: http://register.fluke.com
.
Address correspondence to:
Fluke Corporation Fluke Europe B.V.
P.O. Box 9090, P.O. Box 1186,
Everett, WA 98206-9090 5602 BD Eindhoven
U.S.A. The Netherlands
Limited Warranty & Limitation Of Liability
This Fluke product will be free from defects in material and workmanship for 3 years from
the date of purchase. This warranty does not cover fuses, disposable batteries, or damage
from accident, neglect, misuse, alteration, contamination, or abnormal conditions of
operation or handling. Resellers are not authorized to extend any other warranty on Fluke’s
behalf. To obtain service during the warranty period, contact your nearest Fluke authorized
service center to obtain return authorization information, then send the product to that
Service Center with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS
FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE
FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES,
ARISING FROM ANY CAUSE OR THEORY. Since some states or countries do not allow the
exclusion or limitation of an implied warranty or of incidental or consequential damages,
this limitation of liability may not apply to you.
11/99
