10
2. Safety Warnings
2.1. General Instructions
Signs used to mark instructions in this manual
Safety instructions in these operating instructions,
which, if not observed, could cause a danger for persons
are marked with the general symbol in accordance with
DIN 4844-W 9.
Warnings against electrical voltage are marked with
the safety symbol in accordance with DIN 4844-W 8.
2.2. General Safety Precautions
General regulations and guidelines not mentioned in the
safety warnings retain their validity.
These operating instructions contain basic instruc-
tions, which have to be adhered to during installation, op-
eration and maintenance. These operating instructions
must be read from mechanic and the operator before in-
stallation and operation of the pump and have to be kept
available at the operating place of the machine/unit at all
times. Persons who are not familiar with the operating in-
structions shall not use this product.
If you have to work with welding tools or electric tools,
make sure that there is no explosion hazard.
Immediately after repair or maintenance work, all
safety and protection equipment must be reinstalled and
placed in function again.
Persons are not permitted to stay in the pumping me-
dium during operation of the pump.
In accordance with product liability law, we point out
that we shall not be liable for damages caused by the
pump due to non-observance of the instructions and
guidelines set forth in the operating instructions. The
same product liability are valid for accessories.
3. Applications and Technical Description
3.1. Applications
The working area has to be closed off expediently
and must adhere to local workplace regulations.
HOMA universal pumps are transportble, self-priming,
centrifugal pumps with electric motor. By installation of
the automatic pump control HPS 1 (standard by the mod-
els HCE 60, HCE 63, HCE 71 und HCE 105) on the dis-
charge of the pumps, they work as a pressure booster
unit. The pumps are designed for pumping clear water.
They are used for garden irrigation, emptying of tanks or
as an emergency pumps by flooding.
The pumps must not be used for pumping of liquids con-
taining quamtities of abrasive solids, like sand or stones.
Before pumping of chemically aggressive liquids, the re-
sistance of the pump materials must be checked.
Corresponding to the regulations for sewage disposal
units of explosive environments, it is not allowed to pump
sewage and explosive liquids with these pumps.
3.2 Technichal Data
Discharge BSP 1“IG
Spherical clearance 1 mm
Voltage 230 V / 1 Ph / 50 Hz
Speed 2900 U/min
Insulation class F
Motor protectiont IP 44
Required fuses mindestens 16 A
Suction head max. max. 8 m
Suction pipe dia. min. ¾“
Discharge pipe min. min. ½“
Pre-compression max. 2 bar
Cable 2 m
Cable type H07RN-F...
Noise level during operation, 1,60 m from
the ground
70dbA
Pump specific detail see pump label
3.3. Operating Conditions
Max. medium temperature 35°C
Operation Intermittent
4. Warranty
Our warranty only covers pumps which are installed and
operated in accordance with these installation and opera-
tion instructions and accepted codes of good practice and
being used for the applications mentioned in these in-
structions.
5. Transport and Storage
All other rules and regulations and local codes cover-
ing health and safety must be observed.
Never use the cable or the discharge hose/pipe to lift,
lower, transport or attach the pump. Always use the han-
dle.
The pump may be transported and stored in vertical
or horizontal position. Make sure that it cannot roll or fall
over. For longer periods of storage, the pump should be
protected against moisture, frost or heat.
6. Electrical Connection
Before operation, an expert check must secure that
the required electrical protection measures exist. The
connection to ground, earthing, isolating transformer, fault
current breaker or fault voltags circuit must correspond to
the guidelines set forth by the responsible power plant.
The voltage required in the technical data sheet
must correspond to the existing line voltage.
Make sure that the electrical pin-and-socket connec-
tions are installed flood- and moisture-safe. Before start-
ing operation check the cable and the plug against dam-
ages.
