11 M109
● Adjusting the balance
2-1. Select “BALANCE”.
3-1. Turn the [ROTARY] knob to adjust balance
between right and left speakers.
∗ The factory default setting is “CENTER”.
(Adjustment range: RIGHT12 to LEFT12)
● Adjusting the fader
2-1. Select “FADER”.
3-1. Turn the [ROTARY] knob to adjust balance
between front and rear speakers.
∗ The factory default setting is “CENTER”.
(Adjustment range: FRONT12 to REAR12)
● Adjusting the non-fader volume
Adjust volume output from the unit’s non-fader
output terminal.
2-1. Select “NF VOL”.
3-1. Turn the [ROTARY] knob clockwise to
increase volume; turn counterclockwise to
decrease volume.
∗ The factory default setting is “0”.
(Adjustment range: +6 to –6)
Note:
• When in the sound adjustment mode, if no
operation is performed for 10 seconds or more,
the mode is cancelled and the unit returns to the
previous mode.
Setting the MAGNA BASS EXTEND
The MAGNA BASS EXTEND function does not
adjust low frequencies like normal sound
adjustments, but emphasizes the deep bass
range with dynamic sound.
∗ The factory default setting is “OFF”.
1. Press and hold the [AUDIO] button (1 sec.)
to enable MAGNA BASS EXTEND.
2. Press and hold the [AUDIO] button (1 sec.)
to disable MAGNA BASS EXTEND.
Radio Operations
Changing the reception area
This unit is initially set to USA frequency
intervals of 10 kHz for AM and 200 kHz for FM.
When using it outside the USA, the frequency
reception range should be switched to the
intervals below.
Setting the reception area
∗ All station preset memories are lost when the
reception area is changed.
1. Press the [BND] button and select the
desired radio band (FM or AM).
U.S. standard (initial setting for US model)
2. While pressing the [AUDIO] button, press
and hold the number “1” of the [DIRECT]
buttons for 2 seconds or longer.
Other countries (new setting)
3. While pressing the [AUDIO] button, press
and hold the number “2” of the [DIRECT]
buttons for 2 seconds or longer.
Europe standard (initial setting for Europe
model)
4. While pressing the [AUDIO] button, press
and hold the number “3” of the [DIRECT]
buttons for 2 seconds or longer.
U.S.
standard
Other
countries
Europe
standard
AM
Frequency
spacing
10 kHz 9 kHz 9 kHz
Frequency
range
530 to
1,710 kHz
531 to
1,629 kHz
531 to
1,602 kHz
FM
Frequency
spacing
200 kHz 50 kHz 50 kHz
Frequency
range
87.9 to
107.9 MHz
87.0 to
108.0 MHz
87.5 to
108.0 MHz
