English

Installation

Manual

20 DTX502E

1. Before Starting

1. This set is exclusively for use in cars with a negative ground 12V power

supply.

2. Read these instructions carefully.

3. Be sure to disconnect the battery “-” terminal before starting.

This is to prevent short circuits during installation. (Figure 1)

14. INSTALLATION/WIRE CONNECTION GUIDE

2. Package Contents

Main Unit............................................................1

Remote Control ..................................................1

Battery (CR2025) ...............................................1

(Installed in remote control)

IR Cable .............................................................1

TV Antenna ........................................................2

Power Cable ......................................................1

Extension Cable .................................................1

Connection Cable(10 pin connector) ................1

Connector Cable(RCA) .....................................1

Installation Brackets ...........................................2

Installation Screw M2.6 ......................................4

Installation Screw M3 .........................................4

Warranty Card ....................................................1

Owner’s Manual and Installation Manual ...........1

CONTENTS

1. Before Starting ....................................................................................................... 18

2. Package Contents ................................................................................................. 18

3. General Cautions ................................................................................................... 18

4. Cautions On Installation ......................................................................................... 19

5. Cautions On Wiring ................................................................................................ 19

6. Wire Connections .................................................................................................. 19

7. Car TV Antenna Installation manual ....................................................................... 21

3. General Cautions

1. Do not open the case. There are no user- serviceable parts inside. If you drop anything into the unit during

installation, consult your dealer or an authorized Clarion service center.

2. Use a soft, dry cloth to clean the case. Never use a rough cloth, thinner, benzine, or alcohol etc. For tough dirt,

apply a little cold or warm water to a soft cloth and wipe o the dirt gently.

Figure 1

( Car battery )
