Safety Information
7
Table 2. International Symbols
AC - Alternating current Double insulated
DC - Direct current Battery
Earth ground Refer to the manual for information about
this feature.
Pressure
O
ON/OFF
Conforms to Canadian Standards
Association directives
Conforms to European Union directives
