TASCAM DA-6400/DA-6400dp
31
DA-6400/DA-6400dp
Function added to set the input and output signal routing for each individual channel
Input signal routing can now be set per channel. Output signal
routing can also now be set per channel.
The
INPUT ROUTING 1
and
INPUT ROUTING 2
menu pages
have been replaced by a
ROUTING
page for these functions.
Setting input signal routing
Follow these steps to set input signal routing.
1. Open the
ROUTING
page and select the
INPUT ROUTING
item. Then, press the MULTI JOG dial to open the
INPUT
ROUTING
settings list.
INPUT ROUTING
settings list
NOTE
When an interface card with less than 64 input signal channels
is installed, the names of unavailable input connectors appear
gray.
For example, if an IF-AE16 card with 16 I/O channels is in-
stalled in
SLOT1
, the
SLOT1-17 IN
to
SLOT1-64 IN
items will appear gray.
2. Turn the MULTI JOG dial to select the channel you want
to set, and press the MULTI JOG dial to open the
INPUT
ROUTING
setting screen.
INPUT ROUTING
setting screen
3. Select the
EDIT MODE
item and set how setting values are
changed.
Press the MULTI JOG dial to confirm the EDIT MODE and
move the cursor to the next item. You can also use the .
and / buttons to move the cursor.
Option
Individual
(default): Change settings for one channel
at a time.
8ch BLOCK
: Change settings for eight channels at a time.
BATCH SETUP
: Set a group of multiple channels to be
changed at the same time.
4. Operations differ according to the selected
EDIT MODE
.
o
Individual
selected
The name of the channel selected in step 1 appears to the
left of the selection area.
Turn the MULTI JOG dial to select an input signal.
Options:
SLOT1-01 IN – SLOT1-64 IN
,
SLOT2-01 IN – SLOT2-64 IN
(128 options)
Press the MULTI JOG dial to confirm the setting value and
reopen the
INPUT ROUTING
setting list.
o
8ch BLOCK
selected
An 8-channel block that includes the channel selected in
step 1 appears to the left of the selection area.
Turn the MULTI JOG dial to select an input signal block.
Options:
SLOT1 01-08
,
SLOT1 09-16
,
SLOT1 17-24
,
SLOT1 25-32
,
SLOT1 33-40
,
SLOT1 41-48
,
SLOT1 49-56
,
SLOT1 57-64
,
SLOT2 01-08
,
SLOT2 09-16
,
SLOT2 17-24
,
SLOT2 25-32
,
SLOT2 33-40
,
SLOT2 41-48
,
SLOT2 49-56
,
SLOT2 57-64
(16 options)
Press the MULTI JOG dial to confirm the setting value and
reopen the
INPUT ROUTING
setting list.
o
BATCH SETUP
selected
RANGE SELECT
appears to the left of the selection area.
Press the MULTI JOG or . and /buttons to move the
blue cursor, and turn the MULTI JOG to set the following
values.
o First and last numbers of the range of channels for
which you want to change settings
o Slot number and input connector starting number for
the input signal you want to route
Move the blue cursor to
APPLY
and press the MULTI JOG
dial to open a pop-up confirmation message.
