Tascam DA-6400 [7/36] Cascade status added to information screen

TASCAM DA-6400/DA-6400dp

7

DA-6400/DA-6400dp

5. If you want to conduct recording operations using timecode, the same timecode can also be provided to cascade slave unit by input-

ting a timecode signal into the timecode input connector of the cascade master unit.

NOTE

i If a cascade unit is added to the network during recording or playback,

CASCADE UNITS

will appear for that device's ID. That unit will

not be able to operate with cascade synchronization until the cascade-synchronized recording or playback stops.

i If cascade connection is interrupted due to network connection failure during recording or playback, after the network connection is

Cascade playback

After cascade operation settings and connections have been completed, starting/stopping/pausing playback on the cascade master unit

will simultaneously start/stop/pause playback on the cascade slave unit.

When searching forward/backward on the cascade master unit, the slave unit will not synchronize until after the master unit is stopped.

Then, it will synchronize to the stopping point.

If takes are skipped during playback, the slave unit will synchronize to the master unit playback after it stops skipping. Then, it will also

resume playing.

If takes are skipped when stopped, the slave unit will immediately stop at the same playback take as the master unit.

Takes used for cascade playback

The cascade Master can play back any Take in the current folder whose Sampling rate matches the

When using cascade playback, as a rule, play takes back on the same units that were used for cascade recording.

If you want to use a take that has a CASCADE ID added to its take name for cascade playback that differs from the cascade ID setting,

do one of the following.

Examples:

In this state, cascade playback with “T001_TASCAM_M_001” is not possible. Do one of the following to enable cascade playback of the
