TASCAM DR-701D
11
2 – Names and functions of parts
The various menu items are as follows.
Menu item Function Page
INPUT page
GAIN
Set the input gain. page 20
SEL
Select input sources. page 20
MIXER page
LVL.
Adjust the level.
page 34
PAN
Adjust the left/right balance.
Adjust the mid/side balance
in mid-side mode.
MS
Turn mid-side decoding on/
off.
page 34
PHASE/DELAY page
PHAS
Set the input phase. page 21
DELY
Compensate for mic
distances.
page 21
LEVEL CONTROL page
LIM. Set the limiter. page 23
AUTO
Set automatic level control. page 24
LCF
Set the low-cut filter. page 24
TRIM GANG page
GRP1
Set the group 1 GANG
operation.
page 34
GRP2
Set the group 2 GANG
operation.
OUTPUT LEVEL page
CAMERA
Set the camera output level.
page 18
LINE
Set the line output level.
MIC POWER page
PHAN
Turn phantom power on/off. page 22
VOLTAGE
Set the phantom power
voltage.
page 22
PLUGIN
Set the plug-in power
function.
page 23
RECORD page
SEL
Make recording channel
settings.
page 25
MIX
Make MIX recording settings. page 25
DUAL
Make channel settings
and adjust levels for dual
recording.
page 26
REC SETTING page
FILE TYPE
Set the recording file type.
page 24
FORMAT
Set the recording file format.
SAMPLE
Set the sampling frequency.
Menu item Function Page
FILE page
NAME TYPE
Set the file name format.
page 36
WORD
Set the file name text.
COUNT INIT
Reset the file number.
MEDIA page
BROWSE
Work with files and folders on
the SD card.
page 31
page 32
NEW FOLDER
Make settings for new folder
creation.
page 32
FORMAT
Format SD cards. page 36
TIME CODE page
SELECT
Set the time code source. page 28
POWER OFF
GEN
Set whether or not the
generator runs when the
power is off.
page 29
SLATE TONE page
AUTO
Set the automatic slate tone. page 27
VOLUME
Set the slate tone volume. page 27
OSCILLATOR
Activate the oscillator. page 27
HDMI AUDIO ASSIGN page
SEL
Make HDMI output channel
settings.
page 29
MIX
Make HDMI output MIX
setting.
page 29
METER/TRIM page
PEAK HOLD
Set the peak hold time. page 37
TRIM MIN
Make the trim operation mute
setting.
page 37
POWER MANAGEMENT page
BATTERY TYPE
Set the type of batteries. page 37
AUTO PWR
SAVE
Set the automatic power off
function.
page 37
BACKLIGHT
Set the time until the
backlight turns off.
page 37
REMOTE page
CONTROLLER
Make remote control settings.
page 39
MODE
Set the remote control mode.
SYSTEM page
INITIALIZE
Restore the default settings. page 37
DATE/TIME
Set the date and time. page 15
INFORMATION
Shows a variety of infor-
mation.
page 38
CAUTION
•
During recording, the menu pages from
INPUT
to
OUTPUT LEVEL
will be shown. The
MIC POWER
and
later menu pages will not be shown.
•
The settings for all menu items are retained even when the
unit is turned off.
