Safety instructions
This Application Quick Guide is intended only for use by trained specialists in conjunction with the product manuals
for working on VLT® AQUA Drive FC 200 series frequency converters.
Hazardous voltages are present in the frequency converter when it is connected to the mains. Incorrect installation of the motor,
frequency converter or control cables can cause irreparable damage to the frequency converter or system as well as serious or fatal
injuries.
To prevent electrical shock, the frequency converter must be disconnected from the mains before performing all maintenance work.
The DC link capacitors of the VLT® AQUA Drive FC 200 retain their charge for a very long time even after disconnecting the mains
supply. It is therefore essential to wait for the duration of the period specified on the unit or in the product manual before carrying out
any maintenance work after disconnecting the mains supply.
Always follow the instructions contained in the relevant product manuals as well as local and national rules and safety regulations.
The contents of this Application Quick Guide refer mainly to the basic unit of the VLT® AQUA Drive with graphical control panel
(LCP 102) up to 90 kW (400 V) and initial operation with an asynchronous motor. For the sake of clarity, this Application Quick Guide
does not cover all options and accessories or detailed differences with higher-power models or special variants.
Please refer to the corresponding product manual in all cases.
Содержание
- Table of contents 3
- Connection 4
- Dc link circuit mains 4
- Dc zwischenkreis netz motor 4
- Control terminals in basic unit without a b or c options 6
- Inverter 6
- Only for fc 200 with safe stop 6
- Relay 1 relay 2 6
- See section 1 for a description of switches s201 s202 and s801 the maximum rated voltage on analogue inputs 53 and 54 is 20 v 6
- Function of dip switches in basic unit without a b or c options 8
- Digital input programming options 9
- Selectable not selectable x factory setup see programming manual for details 10
- Graphical control unit lcp 102 11
- Operation via lcp 102 11
- Direction 12
- Explanation of lcp 102 status display 12
- Operating mode 12
- Operating range 12
- Operational status 12
- Parameter set 12
- Reference source 12
- Status line 12
- Warning 12
- Commissioning menu submenu q2 of quick menu 13
- Easy commissioning 13
- Other commonly used parameters in the main menu 14
- Using the lcp copy function parameter 0 50 to transfer device parameters 15
- Parameter setting with mct 10 software 16
- Access via rs 232 ethernet or usb converter 17
- General settings 18
- Profibus dp interface 18
- Fault analysis 19
- Warnings alarms and alarm resetting 19
- If the drive does not restart after an alarm reset 20
- Warning and alarm indications 21
- Application examples 24
- Monitoring on terminal 19 24
- Reference 0 50 hz via terminal 53 motor thermistor 24
- Start stop four pole motor motor thermistor 24
- Start stop four pole motor motor thermistor reference 0 50 hz via terminal 53 motor thermistor monitoring on terminal 19 visual alarm indication 24
- Visual alarm indication 24
- Start stop four pole motor oversynchronous motor thermistor 0 72 hz reference value via terminal 53 motor thermistor monitoring on terminal 19 visual alarm indication 25
- Start stop two pole motor motor thermistor reference 0 50 hz via potentiometer on terminal 53 motor thermistor monitoring on terminal 19 visual alarm indication 26
- Start stop two pole motor oversynchronous motor thermistor 0 72 hz reference value via terminal 53 motor thermistor monitoring on terminal 19 visual alarm indication 27
- Start stop motor thermistor reference 0 50 hz terminal 53 motor thermistor monitoring on terminal 19 visual alarm indication 28
- Fixed speeds three diff erent speeds preset references can be selected via fl oating contacts 29
- Automatic fast ramp the starts up with fast acceleration and then runs with slow acceleration reference 0 1500 rpm via potentiometer 30
- Manual off automatic selection with reference value input via keypad in the switch position auto the reference is active via potentiometer in the switch position manual the reference can be set using the up and down buttons in the switch position off the motor is stopped 31
- Manual off automatic selection with reference value input via potentiometer in switch position auto the reference is active via potentiometer in switch position manual the unit can only be operated via the display in switch position off the motor is stopped 32
- Manual profi bus time out selection with profi bus control the converter does not accept any commands via the terminals if profi bus control is interrupted the converter automatically switches to manual mode reference setting via buttons manual mode can also be selected via terminal 18 33
- Pressure control in pressure control with integrated process controller internal reference feedback 0 100 on terminal 54 34
- Pressure control in pa pressure control with integrated process controller internal reference feedback 0 2000 pa on terminal 54 35
- Pressure control in bar with pipe compensation pressure control using integrated process controller with pipe pressure drop compensation internal reference feedback 0 10 bar on terminal 54 36
- H as 0 20 ma signal on terminal 42 37
- H on terminal 54 feedback output 0 5000 37
- Volume fl ow control in m³ h feedback signal output 0 20 ma volume fl ow control with integrated process controller internal reference feedback 0 5000 37
- H as 0 20 ma signal on terminal 42 38
- H on terminal 54 feedback output 0 5000 38
- Volumetric fl ow control in m³ h oversynchronous feedback signal output 0 20 ma volume fl ow control with integrated process controller internal reference feedback 0 5000 38
- Pressure control in bar basic cascade controller pressure control with integrated process controller the vlt aqua drive cascade controller can switch on additional pumps via the relays if necessary controlled variable 0 10 bar on terminal 54 39
