Danfoss VLT AQUA Drive FC-202P5K5S2 [21/40] Warning and alarm indications
![Danfoss VLT AQUA Drive FC-202P7K5T4 [21/40] Warning and alarm indications](/views2/1557590/page21/bg15.png)
5
5.3 Warning and alarm indications
No. Description Warning Alarm / trip Alarm / Trip-lock See parameter
1 10 V low X
2 Signal fault (X) (X) 6-01
3 No motor (X) 1-80
4 Mains phase imbalance (X) (X) (X) 14-12
5 DC link voltage high X
6 DC link voltage low X
7 DC overvoltage X X
8 DC undervoltage X X
9 Inverter overloaded X X
10 Motor ETR overtemperature (X) (X) 1-90
11 Motor thermistor (X) (X) 1-90
12 Torque limit X (X) 14-25
13 Overcurrent X X X
14 Earth fault X X X
15 Hardware mismatch X X
16 Short circuit X X
17 Control word time-out (X) (X) 8-04
23 Internal fan fault (X) (X) 14-53
24 External fan fault (X) (X) 14-53
25 Brake resistor shorted X
26 Brake resistor power limit (X) (X) 2-13
27 Brake chopper shorted X X
28 Brake resistor test (X) (X) 2-15
