Terminal no. Description Remarks
12, 13 Internal +24 V DC source for powering digital inputs. Maximum load 200 mA
18 Digital input (see parameter 5-10 for function)
0–24 V DC, Ri = 4 kΩ
< 5 V = logic “0” (PNP logic)
> 10 V = logic “1” (PNP logic)
19 Digital input (see parameter 5-11 for function)
20
Reference potential (0 V) for external digital input/output
configuration
Frame potential for terminals 12, 13
27 Digital input/output (see parameters 5-01, 5-12 & 5-30 for function)
Input: see terminals 18 and 19
Output: 0/24 V DC, max. 40 mA
Pulse output: see product manual
29 Digital input/output (see parameters 5-02, 5-13 & 5-31 for function)
32 Digital input (see parameter 5-14 for function)
Input: see terminals 18 and 19
Pulse input: see product guide
33 Digital input (see parameter 5-15 for function)
37
Only for FC 200 with optional safe stop
Digital input for safe stop compliant with EN 954-1 Cat. 3
or EN 13849-1 SIL 2 (see parameter 5-19 for function)
To achieve the safety function, the information in the
design guide must be observed.
39 Ground potential for analogue output 42
42
Scalable analogue output 0/4–20 mA (see parameter 6.5* for
function)
0/4–20 mA, 500 Ω max.
50
Internal +10 V DC power source, for example, for supplying
potentiometer or motor thermistor
10 V DC, max. 15 mA
53, 54
Analogue inputs 0–10 V DC or 0/4–20 mA, selectable
for reference/feedback or motor thermistor
(function: terminal 53, see parameter 6-1*; terminal 54, see
parameter 6-2*;
reference, see parameters 3-15, 3-16 & 3-17; feedback, see
parameter 20-0*; motor thermistor, see parameters 1-93 & 1-90)
0 to +10 V, scalable, Ri approx. 10 kΩ;
0 to 20 mA, scalable, Ri approx. 200 Ω
V/mA selection; see S201/S202
Note: maximum voltage on analogue inputs
20 V.
55 Ground potential for analogue inputs 53 and 54
61 Integrated RC decoupling Do not use
68 (+), 69 (-) RS 485 serial interface (see parameter 8-3* for function) Max. 115 kbit/s
01, 02, 03 Relay output 1 (see parameter 5-40 [0] for function)
Max. 240 V AC, 2 A (resistive load)
See the design guide for further information.
04, 05, 06 Relay output 2 (see parameter 5-40 [1] for function)
1
