4-61 Bypass Speed From [Hz]
Array [4]
Range: Function:
Size related* [ 0
- par.
4-14
Hz]
Some systems call for avoiding
certain output speeds due to
resonance problems in the system.
Enter the lower limits of the speeds
to be avoided.
4-62 Bypass Speed To [RPM]
Array [4]
Range: Function:
Size related* [ 0
- par. 4-13
RPM]
Some
systems call for avoiding
certain output speeds due to
resonance problems in the system.
Enter the upper limits of the
speeds to be avoided.
4-63 Bypass Speed To [Hz]
Array [4]
Range: Function:
Size related* [ 0 - par.
4-14
Hz]
Some systems call for avoiding
certain output speeds due to
resonance problems in the system.
Enter the upper limits of the
speeds to be avoided.
4-64 Semi-Auto Bypass Set-up
Option: Function:
[0] * Off No function
[1] Enabled Starts the Semi-Automatic Bypass set-up and
continue
with the procedure described above.
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
58 MG16H102 - VLT
®
is a registered Danfoss trademark
