[196] Fire Mode The frequency converter is operating in
Fire
Mode. See 24-0* Fire Mode.
[197] Fire Mode was
act.
The frequency converter has been
operating
in Fire Mode, but is now back
in normal operation.
[198] Drive Bypass To be used as signal for activating an
external
electromechanical bypass
switching the motor direct on line. See
24-1* Drive Bypass.
CAUTION
If enabling the Drive Bypass Function,
the
frequency converter is no longer
Safety Certified (for using the Safe
Stop in versions where included).
[199] Injection
Control
Indicates that the digital output is used
for
providing Injection ON-OFF signal. A
low voltage on the selected digital output
indicates Injection OFF, while high voltage
indicates Injection ON.
The below setting options are all related to the Cascade
Controller.
Wiring
diagrams and settings for meter, see parameter
group 25-** for more details.
[200] Full Capacity All pumps running and at full speed
[201] Compressor 1
Running
One or more of the compressors
controlled
by the Cascade Controller are
running. The function will also depend on
the setting of in Fixed Lead Compressor,
25-06. If set to [0] No Compressor 1 refers
to the compressor controlled by relay
RELAY1 etc. If set to [1] Yes Compressor 1
refers to the compressor controlled by the
frequency converter only (without any of
the build in relays involved) and
Compressor 2 to the compressor
controlled by the relay RELAY1. See
Table 3.13:
[202] Compressor 2
Running
See [201]
[203] Compressor 3
Running
See [201]
Setting in parameter group 5-3* Setting in parameter 25-06
[0] No [1] Yes
[201] Compressor 1 Running Controlled by RELAY1 Frequency Converter controlled
[202] Compressor 2 Running Controlled by RELAY2 Controlled by RELAY1
[203] Compressor 3 Running Controlled by RELAY3 Controlled by RELAY2
Table 3.13
5-30 Terminal 27 Digital Output
Option: Function:
[0] * No operation Functions are described under parameter
group
5-3*
5-31 Terminal 29 Digital Output
Option: Function:
[0] * No operation Functions are described under parameter
group
5-3*
5-32 Term X30/6 Digi Out (MCB 101)
Option: Function:
[0] * No operation This meter is active when option module
MCB
101 is mounted in the frequency
converter. Functions are described under
parameter group 5-3*
5-33 Term X30/7 Digi Out (MCB 101)
Option: Function:
[0] * No operation This meter is active when option module
MCB
101 is mounted in the frequency
converter. Functions are described under
parameter group 5-3*
3.7.4 5-4* Relays
Parameters for configuring the timing and the output
functions
for the relays.
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
66 MG16H102 - VLT
®
is a registered Danfoss trademark
33
